Oh Chentaku vol.3

HWiNFO® 64 v8.22-5670

Creation Time		31.03.2025 02:42

Content: CPU Motherboard Memory Video Monitor Drives Network

OH-CHENTAKU

---

[Current Computer]
	Computer Name:	OH-CHENTAKU
	Computer Brand Name:	GIGABYTE H410M S2 V3
[Operating System]
	Operating System:	Microsoft Windows 10 Professional (x64) Build 19045.5487 (22H2)
	UEFI Boot:	Present
	Secure Boot:	Disabled
	Hypervisor-protected Code Integrity (HVCI):	Disabled

Central Processor(s)

---

[CPU Unit Count]
	Number Of Processor Packages (Physical):	1
	Number Of Processor Cores:	6
	Number Of Logical Processors:	12

Intel Core i5-10400F

---

[General Information]
	Processor Name:	Intel Core i5-10400F
	Original Processor Frequency:	2900.0 MHz
	Original Processor Frequency [MHz]:	2900
	CPU ID:	000A0653
	CPU Brand Name:	Intel(R) Core(TM) i5-10400F CPU @ 2.90GHz
	CPU Vendor:	GenuineIntel
	CPU Stepping:	G1
	CPU Code Name:	Comet Lake-S
	CPU Technology:	14 nm
	CPU S-Spec:	SRH3D
	CPU Thermal Design Power (TDP):	65.0 W
	CPU Power Limits (Max):	Power = Unlimited, Time = Unlimited
	CPU Power Limit 1 (Long Duration)/Processor Base Power (PBP):	(85.00 W) (28.00 sec) [Unlocked]
	CPU Power Limit 2 (Short Duration)/Maximum Turbo Power (MTP):	(134.00 W) (Unlimited) [Unlocked]
	CPU Max. Junction Temperature (Tj,max):	100 °C
	CPU Type:	Production Unit
	CPU Platform:	Socket H (LGA1200)
	Microcode Update Revision:	EA
	Number of CPU Cores:	6
	Number of Logical CPUs:	12
[Operating Points]
	CPU LFM (Minimum):	800.0 MHz = 8 x 100.0 MHz
	CPU HFM (Base):	2900.0 MHz = 29 x 100.0 MHz
	CPU Turbo Max:	4300.0 MHz = 43 x 100.0 MHz [Unlocked]
	Maximum Per-core Ratio Limits (Fused):	43, 43, 43, 43, 43, 43
	Maximum Per-core Ratio Limits (Current):	43, 43, 43, 43, 43, 43
	CPU Current:	3990.2 MHz = 40 x 99.8 MHz @ 1.0812 V
	LLC/Ring Maximum:	4000.0 MHz = 40.00 x 100.0 MHz
	LLC/Ring Current:	3691.0 MHz = 37.00 x 99.8 MHz
	System Agent Current:	997.6 MHz = 10.00 x 99.8 MHz
	CPU Bus Type:	Intel Direct Media Interface (DMI) v3.0
	Maximum DMI Link Speed:	8.0 GT/s
	Current DMI Link Speed:	8.0 GT/s
	Ring to Core Offset:	Enabled
[IA Overclocking]
	Voltage Offset:	Supported
	Voltage Override:	Supported
	Ratio Overclocking:	Not Supported
	Fused Ratio Limit:	43x
	OC Ratio Limit:	N/A
	Voltage Mode:	Interpolative
	Voltage Offset (Global):	0 mV
	IccMax:	160.00 A
[GT (Slice) Overclocking]
	Voltage Offset:	Supported
	Voltage Override:	Supported
	Ratio Overclocking:	Not Supported
	Fused Ratio Limit:	16x
	OC Ratio Limit:	N/A
	Voltage Mode:	Interpolative
	Voltage Offset (Global):	0 mV
	IccMax:	160.00 A
[CLR (CBo/LLC/Ring) Overclocking]
	Voltage Offset:	Supported
	Voltage Override:	Supported
	Ratio Overclocking:	Not Supported
	Fused Ratio Limit:	40x
	OC Ratio Limit:	N/A
	Voltage Mode:	Interpolative
	Voltage Offset (Global):	0 mV
	IccMax:	160.00 A
[GT (Unslice) Overclocking]
	Voltage Offset:	Supported
	Voltage Override:	Supported
	Ratio Overclocking:	Not Supported
	Fused Ratio Limit:	16x
	OC Ratio Limit:	N/A
	Voltage Mode:	Interpolative
	Voltage Offset (Global):	0 mV
	IccMax:	160.00 A
[Uncore/SA Overclocking]
	Voltage Offset:	Supported
	Voltage Override:	Not Supported
	Ratio Overclocking:	Not Supported
	Fused Ratio Limit:	N/A
	OC Ratio Limit:	N/A
	Voltage Mode:	Interpolative
	Voltage Offset (Global):	0 mV
	IccMax:	20.00 A
	IA Domain Loadline (AC/DC):	0.900 / 0.900 mOhm
	GT Domain Loadline (AC/DC):	20.027 / 20.027 mOhm
[Cache and TLB]
	L1 Cache:	Instruction: 6 x 32 KBytes, Data: 6 x 32 KBytes
	L2 Cache:	Integrated: 6 x 256 KBytes
	L3 Cache:	12 MBytes
	Instruction TLB:	2MB/4MB Pages, Fully associative, 8 entries
	Data TLB:	4 KB Pages, 4-way set associative, 64 entries
[Standard Feature Flags]
	FPU on Chip	Present
	Enhanced Virtual-86 Mode	Present
	I/O Breakpoints	Present
	Page Size Extensions	Present
	Time Stamp Counter	Present
	Pentium-style Model Specific Registers	Present
	Physical Address Extension	Present
	Machine Check Exception	Present
	CMPXCHG8B Instruction	Present
	APIC On Chip / PGE (AMD)	Present
	Fast System Call	Present
	Memory Type Range Registers	Present
	Page Global Feature	Present
	Machine Check Architecture	Present
	CMOV Instruction	Present
	Page Attribute Table	Present
	36-bit Page Size Extensions	Present
	Processor Number	Not Present
	CLFLUSH Instruction	Present
	Debug Trace and EMON Store	Present
	Internal ACPI Support	Present
	MMX Technology	Present
	Fast FP Save/Restore (IA MMX-2)	Present
	Streaming SIMD Extensions	Present
	Streaming SIMD Extensions 2	Present
	Self-Snoop	Present
	Multi-Threading Capable	Present
	Automatic Clock Control	Present
	IA-64 Processor	Not Present
	Signal Break on FERR	Present
	Virtual Machine Extensions (VMX)	Present
	Safer Mode Extensions (Intel TXT)	Not Present
	Streaming SIMD Extensions 3	Present
	Supplemental Streaming SIMD Extensions 3	Present
	Streaming SIMD Extensions 4.1	Present
	Streaming SIMD Extensions 4.2	Present
	AVX Support	Present
	Fused Multiply Add (FMA)	Present
	Carryless Multiplication (PCLMULQDQ)/GFMUL	Present
	CMPXCHG16B Support	Present
	MOVBE Instruction	Present
	POPCNT Instruction	Present
	XSAVE/XRSTOR/XSETBV/XGETBV Instructions	Present
	XGETBV/XSETBV OS Enabled	Present
	Float16 Instructions	Present
	AES Cryptography Support	Present
	Random Number Read Instruction (RDRAND)	Present
	Extended xAPIC	Present
	MONITOR/MWAIT Support	Present
	Thermal Monitor 2	Present
	Enhanced SpeedStep Technology	Present
	L1 Context ID	Not Present
	Send Task Priority Messages Disabling	Present
	Processor Context ID	Present
	Direct Cache Access	Not Present
	TSC-deadline Timer	Present
	Performance/Debug Capability MSR	Present
	IA32 Debug Interface Support	Present
	64-Bit Debug Store	Present
	CPL Qualified Debug Store	Present
[Extended Feature Flags]
	64-bit Extensions	Present
	RDTSCP and TSC_AUX Support	Present
	1 GB large page support	Present
	No Execute	Present
	SYSCALL/SYSRET Support	Present
	Bit Manipulation Instructions Set 1	Present
	Bit Manipulation Instructions Set 2	Present
	Advanced Vector Extensions 2 (AVX2)	Present
	Advanced Vector Extensions 512 (AVX-512) Foundation	Not Present
	AVX-512 Prefetch Instructions	Not Present
	AVX-512 Exponential and Reciprocal Instructions	Not Present
	AVX-512 Conflict Detection Instructions	Not Present
	AVX-512 Doubleword and Quadword Instructions	Not Present
	AVX-512 Byte and Word Instructions	Not Present
	AVX-512 Vector Length Extensions	Not Present
	AVX-512 52-bit Integer FMA Instructions	Not Present
	Secure Hash Algorithm (SHA) Extensions	Not Present
	Software Guard Extensions (SGX) Support	Present
	Supervisor Mode Execution Protection (SMEP)	Present
	Supervisor Mode Access Prevention (SMAP)	Present
	Hardware Lock Elision (HLE)	Not Present
	Restricted Transactional Memory (RTM)	Not Present
	Memory Protection Extensions (MPX)	Present
	Read/Write FS/GS Base Instructions	Present
	Enhanced Performance String Instruction	Present
	INVPCID Instruction	Present
	RDSEED Instruction	Present
	Multi-precision Add Carry Instructions (ADX)	Present
	PCOMMIT Instructions	Not Present
	CLFLUSHOPT Instructions	Present
	CLWB Instructions	Not Present
	Time-Stamp Counter Adjustment	Present
	Platform Quality of Service Monitoring (PQM)	Not Present
	Platform Quality of Service Enforcement (PQE)	Not Present
	FPU Data Pointer updated only on x87 Exceptions	Not Present
	Deprecated FPU CS and FPU DS	Present
	Intel Processor Trace	Present
	PREFETCHWT1 Instruction	Not Present
	AVX-512 Vector Bit Manipulation Instructions	Not Present
	AVX-512 Vector Bit Manipulation Instructions 2	Not Present
	AVX-512 Galois Fields New Instructions	Not Present
	AVX-512 Vector AES	Not Present
	AVX-512 Vector Neural Network Instructions	Not Present
	AVX-512 Bit Algorithms	Not Present
	AVX-512 Carry-Less Multiplication Quadword (VPCLMULQDQ)	Not Present
	AVX-512 Vector POPCNT (VPOPCNTD/VPOPCNTQ)	Not Present
	User-Mode Instruction Prevention	Not Present
	Protection Keys for User-mode Pages	Not Present
	OS Enabled Protection Keys	Not Present
	Wait and Pause Enhancements (WAITPKG)	Not Present
	Total Memory Encryption	Not Present
	Key Locker	Not Present
	57-bit Linear Addresses, 5-level Paging	Not Present
	Read Processor ID	Not Present
	OS Bus-Lock Detection	Not Present
	Cache Line Demote	Not Present
	MOVDIRI: Direct Stores	Not Present
	MOVDIR64B: Direct Stores	Not Present
	ENQCMD: Enqueue Stores	Not Present
	SGX Launch Configuration	Present
	Protection Keys for Supervisor-Mode Pages	Not Present
	Control-Flow Enforcement Technology (CET) Shadow Stack	Not Present
	Attestation Services for Intel SGX	Not Present
	AVX-512 4 x Vector Neural Network Instructions Word Variable Precision	Not Present
	AVX-512 4 x Fused Multiply Accumulation Packed Single Precision	Not Present
	Fast Short REP MOV	Not Present
	User Interrupts	Not Present
	AVX-512 VP2INTERSECT Support	Not Present
	AVX-512 FP16	Not Present
	MD_CLEAR Support	Present
	IA32_MCU_OPT_CTRL MSR Support	Not Present
	Restricted Transactional Memory (RTM) Always Abort	Not Present
	Restricted Transactional Memory (RTM) Force Abort	Not Present
	SERIALIZE	Not Present
	Hybrid Processor	Not Present
	TSX Suspend Load Address Tracking	Not Present
	Platform Configuration (PCONFIG)	Not Present
	Architectural LBRs	Not Present
	Indirect Branch Restricted Speculation (IBRS), Indirect Branch Predictor Barrier (IBPB)	Present
	Single Thread Indirect Branch Predictors (STIBP)	Present
	L1D_FLUSH Support	Present
	IA32_ARCH_CAPABILITIES MSR	Present
	IA32_CORE_CAPABILITIES MSR	Not Present
	Speculative Store Bypass Disable (SSBD)	Present
	Control-Flow Enforcement Technology (CET) Indirect Branch Tracking	Not Present
	Advanced Matrix Extensions (AMX) Tile Architecture	Not Present
	Advanced Matrix Extensions (AMX) bfloat16 Support	Not Present
	Advanced Matrix Extensions (AMX) 8-bit Integer Operations	Not Present
	SHA512 Instructions	Not Present
	SM3 Instructions	Not Present
	SM4 Instructions	Not Present
	Advanced Matrix Extensions (AMX) FP16 Instructions	Not Present
	AVX (VEX-encoded) Vector Neural Network Instructions	Not Present
	AVX-512 BFLOAT16 Instructions	Not Present
	Fast Zero-Length MOVSB	Not Present
	Fast Short STOSB	Not Present
	Fast Short CMPSB, SCASB	Not Present
	History Reset	Not Present
	Linear Address Masking	Not Present
	Linear Address Space Separation	Not Present
	RAO-INT Instructions	Not Present
	CMPccXADD Instructions	Not Present
	Flexible Return and Event Delivery (FRED)	Not Present
	LKGS Instruction	Not Present
	WRMSRNS Instruction	Not Present
	NMI-source Reporting	Not Present
	AVX-IFMA Instructions	Not Present
	RD/WR MSRLIST Instructions	Not Present
	INVD Execution Prevention After BIOS-Done	Not Present
	Move Read-Shared Value (MOVRS)	Not Present
	Protected Processor Inventory Number (IA32_PPIN) Support	Not Present
	PBNDKB Instruction	Not Present
	X86S (Legacy-reduced OS ISA)	Not Present
	64-bit SIPI	Not Present
	RDMSR/WRMSR Immediate Forms	Not Present
	AVX-VNNI-INT8 Instructions	Not Present
	AVX-VNNI-INT16 Instructions	Not Present
	AVX-NE-CONVERT Instructions	Not Present
	PREFETCHIT0/1 Instructions	Not Present
	URDMSR/UWRMSR Instructions	Not Present
	AMX-COMPLEX Instructions	Not Present
	CET Supervisor Shadow-Stack	Not Present
	UIRET Support	Not Present
	Advanced Vector Extensions 10 (AVX10)	Not Present
	Advanced Performance Extensions (APX) Foundation	Not Present
	Not Exhibiting MXCSR Configuration Dependent Timing (MCDT)	Not Present
	UC-Lock Disable Feature	Not Present
[Vulnerability Mitigation Mechanisms]
	Rogue Data Cache Load (RDCL):	Not Susceptible
	Speculative Store Bypass (SSB):	Susceptible
	Microarchitectural Data Sampling (MDS):	Not Susceptible
	MCE on modifying code page size without TLB invalidation:	Susceptible
	Transactional Asynchronous Abort (TAA):	Affected
	Shared Buffers Data Read (SBDR), Sideband Stale Data Propagator (SSDP) Vulnerability:	Affected
	Fill Buffer Stale Data Propagator (FBSDP) Vulnerability:	Affected
	Primary Stale Data Propagator (PSDP) Vulnerability:	Affected
	Post-barrier Return Stack Buffer Predictions Vulnerability:	Affected
	Indirect Branch Restriction Speculation (IBRS):	Supported
	RTM_DISABLE and TSX_CPUID_CLEAR:	Not Supported
	RSB Alternate:	Not Supported
	L1D Flush on VM Entry Not Needed:	Supported
	Data Operand Independent Timing Mode (DOITM):	Not Supported
	Energy Filtering Control:	Not Supported
	Data Operand Independent Timing Mode:	Not Supported
	RRSBA Alternate Prediction Behavior:	Not Supported
	BHI_NO Branch Prediction Behavior:	Not Supported
	MCU Enumeration MSR:	Not Supported
	MCU Extended Servicing:	Not Supported
[Enhanced Features]
	Thermal Monitor 1:	Supported, Enabled
	Thermal Monitor 2:	Supported, Enabled
	Enhanced Intel SpeedStep (GV3):	Supported, Enabled
	Bi-directional PROCHOT#:	Enabled
	Extended Auto-HALT State C1E:	Enabled
	MLC Streamer Prefetcher	Supported, Enabled
	MLC Spatial Prefetcher	Supported, Enabled
	DCU Streamer Prefetcher	Supported, Enabled
	DCU IP Prefetcher	Supported, Enabled
	Intel Dynamic Acceleration (IDA) Technology:	Not Supported
	Intel Dynamic FSB Switching:	Not Supported
	Intel Turbo Boost Technology:	Supported, Enabled
	Programmable Ratio Limits:	Supported, Disabled
	Programmable TDC/TDP Limits:	Supported, Disabled
	Hardware Duty Cycling:	Supported, Enabled
	Intel Speed Select:	Not Supported
[CPU SKU Features]
	Display HD Audio:	Supported
	DMI x4 Width:	Supported
	DRAM ECC:	Not Supported
	VT-d:	Supported
	DMI in Gen2 Mode:	Supported
	PEG in Gen2 Mode:	Supported
	1N Mode DDR Timings:	Supported
	Camarillo (DTT) Device:	Supported
	2 DIMMs per Channel:	Not Supported
	X2APIC:	Supported
	Dual Memory Channel:	Supported
	Integrated GPU (IGD):	Disabled
	DDR Overclocking:	Disabled
	Overclocking by DSKU:	Disabled
	DDR3L:	Supported
	Maximum Memory Size per Channel:	64 GB (unlimited)
	DDR Frequency Support (100 MHz RefClk):	Not Supported
	Overclocking:	Disabled
	Hyper-Threading (SMT):	Supported
	Additive Graphics:	Disabled
	PCIe Gen 3:	Supported
	DMI Gen 3:	Supported
	HDCP:	Not Supported
	DDR4:	Supported
	LPDDR3:	Not Supported
	BCLK OC Limit:	100 MHz
	Maximum Supported LPDDR3 Frequency:	1067 MHz
	Maximum Supported DDR4 Frequency:	1333 MHz
	SVID Status:	Enabled
[Voltage Regulator (SVID)]
	VCC VR:	ON Semi (0x29), IMVP8
	VR Thermal Sensor:	Supported
[Memory Ranges]
	Maximum Physical Address Size:	39-bit (512 GBytes)
	Maximum Virtual Address Size:	48-bit (256 TBytes)
[MTRRs]
	Range 80000000-100000000 (2048MB-4096MB) Type:	Uncacheable (UC)
	Range 40000000-80000000 (1024MB-2048MB) Type:	Uncacheable (UC)
	Range 2000000000-4000000000 (131072MB-262144MB) Type:	Uncacheable (UC)
	Range 1000000000-2000000000 (65536MB-131072MB) Type:	Uncacheable (UC)
	Range 4000000000-8000000000 (262144MB-524288MB) Type:	Uncacheable (UC)

Motherboard

---

[Computer]
	Computer Brand Name:	GIGABYTE H410M S2 V3
[Motherboard]
	Motherboard Model:	GIGABYTE H410M S2 V3
	Motherboard Chipset:	Intel H510 (Rocket Lake PCH-H)
	Motherboard Slots:	4xPCI Express x1, 1xPCI Express x4, 1xPCI Express x16
	PCI Express Version Supported:	v3.0
	USB Version Supported:	v3.2
[BIOS]
	BIOS Manufacturer:	American Megatrends International, LLC.
	BIOS Date:	11/01/2021
	BIOS Version:	F4
	UEFI BIOS:	Capable
	Super-IO/LPC Chip:	ITE IT8688E/BX
	Trusted Platform Module (TPM) Chip:	Hardware TPM, version 2.0

ACPI Devices

---

Intel(R) Serial IO GPIO Host Controller - INT34C6

---

	Device Name:	Intel(R) Serial IO GPIO Host Controller - INT34C6
[Assigned Resources]
	Memory Location:	FD6A0000 - FD6AFFFF
	IRQ:	14
[Alternative 1]
	Memory Location:	FD6E0000
	Memory Location:	FD6D0000 - FD6DFFFF
	Memory Location:	FD6B0000 - FD6BFFFF
	Memory Location:	FD6A0000
	Memory Location:	FD690000 - FD69FFFF
	IRQ:	14

Motherboard resources

---

	Device Name:	Motherboard resources
[Assigned Resources]
	I/O Port:	1854 - 1857
[Alternative 1]
	I/O Port:	1854 - 1857

Trusted Platform Module 2.0

---

	Device Name:	Trusted Platform Module 2.0
[Assigned Resources]
	Memory Location:	FED40000 - FED44FFF
[Alternative 1]
	Memory Location:	FED40000 - FED44FFF

Programmable interrupt controller

---

	Device Name:	Programmable interrupt controller
[Assigned Resources]
	I/O Port:	0020 - 0021
	I/O Port:	0030 - 0031
	I/O Port:	00A0 - 00A1
	I/O Port:	00B0 - 00B1
	IRQ:	1114369
	IRQ:	1114369
	IRQ:	1114369
	IRQ:	1114369
[Alternative 1]
	I/O Port:	0020 - 0021
	I/O Port:	0024 - 0025
	I/O Port:	0028 - 0029
	I/O Port:	002C - 002D
	I/O Port:	0030 - 0031
	I/O Port:	0034 - 0035
	I/O Port:	0038 - 0039
	I/O Port:	003C - 003D
	I/O Port:	00A0 - 00A1
	I/O Port:	00A4 - 00A5
	I/O Port:	00A8 - 00A9
	I/O Port:	00AC - 00AD
	I/O Port:	00B0 - 00B1
	I/O Port:	00B4 - 00B5
	I/O Port:	00B8 - 00B9
	I/O Port:	00BC - 00BD
	I/O Port:	04D0 - 04D1

System timer

---

	Device Name:	System timer
[Assigned Resources]
	I/O Port:	0040 - 0043
	DMA:	0
[Alternative 1]
	I/O Port:	0040 - 0043
	I/O Port:	0050 - 0053
	IRQ:	0

High precision event timer

---

	Device Name:	High precision event timer
[Assigned Resources]
	Memory Location:	FED00000 - FED003FF
[Alternative 1]
	Memory Location:	FED00000 - FED003FF

Communications Port

---

	Device Name:	Communications Port
[Assigned Resources]
	I/O Port:	03F8 - 03FF
[Alternative 1]
	I/O Port:	03F8 - 03FF
	IRQ:	4
[Alternative 2]
	I/O Port:	03F8 - 03FF
	IRQ:	3
	IRQ:	4
	IRQ:	5
	IRQ:	7
	IRQ:	9
	IRQ:	10
	IRQ:	11
	IRQ:	12
[Alternative 3]
	I/O Port:	02F8 - 02FF
	IRQ:	3
	IRQ:	4
	IRQ:	5
	IRQ:	7
	IRQ:	9
	IRQ:	10
	IRQ:	11
	IRQ:	12
[Alternative 4]
	I/O Port:	03E8 - 03EF
	IRQ:	3
	IRQ:	4
	IRQ:	5
	IRQ:	7
	IRQ:	9
	IRQ:	10
	IRQ:	11
	IRQ:	12
[Alternative 5]
	I/O Port:	02E8 - 02EF
	IRQ:	3
	IRQ:	4
	IRQ:	5
	IRQ:	7
	IRQ:	9
	IRQ:	10
	IRQ:	11
	IRQ:	12

PCI Express Root Complex

---

	Device Name:	PCI Express Root Complex
[Assigned Resources]
	I/O Port:	0000 - FFFFFFFF
	Memory Location:	000A0000 - 000BFFFF
	Memory Location:	000E4000 - 000E3FFF
	Memory Location:	000EC000 - 000EFFFF
[Alternative 1]
	I/O Port:	0000 - 0CF7
	I/O Port:	0D00 - FFFF
	Memory Location:	000A0000 - 000BFFFF
	Memory Location:	000E0000 - 000E3FFF
	Memory Location:	000E4000 - 000E7FFF
	Memory Location:	000E8000
	Memory Location:	000EC000
	Memory Location:	000F0000
	Memory Location:	40000000

Motherboard resources

---

	Device Name:	Motherboard resources
[Assigned Resources]
	I/O Port:	0A00 - 0A2F
[Alternative 1]
	I/O Port:	0A00 - 0A2F
	I/O Port:	0A30 - 0A3F
	I/O Port:	0A40 - 0A4F

Motherboard resources

---

	Device Name:	Motherboard resources
[Assigned Resources]
	Memory Location:	FED10000 - FED17FFF
	Memory Location:	FED20000 - FED7FFFF
[Alternative 1]
	Memory Location:	FED10000 - FED17FFF
	Memory Location:	FEDA0000 - FEDA0FFF
	Memory Location:	FEDA1000 - FEDA1FFF
	Memory Location:	E0000000
	Memory Location:	FED20000
	Memory Location:	FED90000
	Memory Location:	FED45000
	Memory Location:	FEE00000

Motherboard resources

---

	Device Name:	Motherboard resources
[Assigned Resources]
	Memory Location:	FC000000 - FC00FFFF
[Alternative 1]
	Memory Location:	FC000000 - FC00FFFF

Motherboard resources

---

	Device Name:	Motherboard resources
[Assigned Resources]
	I/O Port:	002E - 002F
	I/O Port:	0065
	I/O Port:	0000 - 006F
	I/O Port:	0092
	IRQ:	1114369
[Alternative 1]
	I/O Port:	002E - 002F
	I/O Port:	004E - 004F
	I/O Port:	0061
	I/O Port:	0063
	I/O Port:	0065
	I/O Port:	0067
	I/O Port:	0070
	I/O Port:	0080
	I/O Port:	0092
	I/O Port:	00B2 - 00B3
	I/O Port:	0680 - 069F
	I/O Port:	164E - 164F

Motherboard resources

---

	Device Name:	Motherboard resources
[Assigned Resources]
	I/O Port:	2000 - 20FE
[Alternative 1]
	I/O Port:	2000 - 20FE

Motherboard resources

---

	Device Name:	Motherboard resources
[Assigned Resources]
	Memory Location:	FE000000 - FE01FFFF
	Memory Location:	FE200000 - FE7FFFFF
[Alternative 1]
	I/O Port:	1800 - 18FE
	Memory Location:	FE000000 - FE01FFFF
	Memory Location:	FE04C000 - FE04FFFF
	Memory Location:	FE050000
	Memory Location:	FE0D0000
	Memory Location:	FE200000
	Memory Location:	FF000000
	Memory Location:	FD000000
	Memory Location:	FD6C0000
	Memory Location:	FD6F0000

Numeric data processor

---

	Device Name:	Numeric data processor
[Assigned Resources]
	I/O Port:	00F0
[Alternative 1]
	I/O Port:	00F0
	IRQ:	13

SMBIOS DMI

---

BIOS

---

	BIOS Vendor:	American Megatrends International, LLC.
	BIOS Version:	F4
	BIOS Release Date:	11/01/2021
	BIOS Start Segment:	F000
	BIOS Size:	16 MBytes
	System BIOS Version:	5.19
	ISA Support:	Not Present
	MCA Support:	Not Present
	EISA Support:	Not Present
	PCI Support:	Present
	PC Card (PCMCIA) Support:	Not Present
	Plug-and-Play Support:	Not Present
	APM Support:	Not Present
	Flash BIOS:	Present
	BIOS Shadow:	Present
	VL-VESA Support:	Not Present
	ESCD Support:	Not Present
	Boot from CD:	Present
	Selectable Boot:	Present
	BIOS ROM Socketed:	Present
	Boot from PC Card:	Not Present
	EDD Support:	Present
	NEC PC-98 Support:	Not Present
	ACPI Support:	Not Present
	USB Legacy Support:	Present
	AGP Support:	Not Present
	I2O Boot Support:	Not Present
	LS-120 Boot Support:	Not Present
	ATAPI ZIP Drive Boot Support:	Not Present
	IEE1394 Boot Support:	Not Present
	Smart Battery Support:	Not Present
	BIOS Boot Specification Support:	Present
	Function key-initiated Network Service Boot Support:	Not Present
	Targeted Content Distribution Support:	Present
	UEFI Specification Support:	Present
	Virtual Machine:	Not Present

System

---

	System Manufacturer:	Gigabyte Technology Co., Ltd.
	Product Name:	H410M S2 V3
	Product Version:
	Product Serial Number:
	UUID:	{035E02D8-04D3-0541-5A06-C20700080009}
	SKU Number:
	Family:	H510 MB

Mainboard

---

	Mainboard Manufacturer:	Gigabyte Technology Co., Ltd.
	Mainboard Name:	H410M S2 V3
	Mainboard Version:	x.x
	Mainboard Serial Number:
	Asset Tag:
	Location in chassis:

System Enclosure

---

	Manufacturer:
	Case Type:	Desktop
	Version:
	Serial Number:
	Asset Tag Number:

On Board Device

---

	Device Description:	To Be Filled By O.E.M.
	Device Type:	Video Adapter
	Device Status:	Enabled

OEM Strings

---

		Default string

System Configuration Options

---

		Default string

System Boot Information

---

	Boot Status:	No error occurred

Management Device

---

	Device Description:	LM78-1
	Device Type:	National Semiconductor LM78
	Device Address:	I/O: 0

Voltage Probe

---

	Description:	LM78A
	Location:	Motherboard
	Status:	OK
	Maximum Value:	Unknown
	Minimum Value:	Unknown
	Resolution:	Unknown
	Tolerance:	Unknown
	Accuracy:	Unknown

Management Device Threshold Data

---

Management Device Component

---

Temperature Probe

---

	Description:	LM78A
	Location:	Motherboard
	Status:	OK
	Maximum Value:	Unknown
	Minimum Value:	OK
	Nominal Value:	OK
	Resolution:	OK
	Tolerance:	OK
	Accuracy:	Unknown

Management Device Threshold Data

---

Management Device Component

---

Cooling Device

---

	Type:	Power Supply Fan
	Description:	Cooling Dev 1
	Status:	OK

Management Device Threshold Data

---

Management Device Component

---

Cooling Device

---

	Type:	Power Supply Fan
	Description:
	Status:	OK

Management Device Threshold Data

---

Management Device Component

---

Electrical Current Probe

---

	Description:	ABC
	Location:	Motherboard
	Status:	OK
	Maximum Value:	Unknown
	Minimum Value:	Unknown
	Resolution:	Unknown
	Tolerance:	Unknown
	Accuracy:	Unknown

Management Device Threshold Data

---

Management Device Component

---

Voltage Probe

---

	Description:	LM78A
	Location:	Power Unit
	Status:	OK
	Maximum Value:	Unknown
	Minimum Value:	Unknown
	Resolution:	Unknown
	Tolerance:	Unknown
	Accuracy:	Unknown

Temperature Probe

---

	Description:	LM78A
	Location:	Power Unit
	Status:	OK
	Maximum Value:	Unknown
	Minimum Value:	OK
	Nominal Value:	OK
	Resolution:	OK
	Tolerance:	OK
	Accuracy:	Unknown

Cooling Device

---

	Type:	Power Supply Fan
	Description:	Cooling Dev 1
	Status:	OK

Electrical Current Probe

---

	Description:	ABC
	Location:	Power Unit
	Status:	OK
	Maximum Value:	Unknown
	Minimum Value:	Unknown
	Resolution:	Unknown
	Tolerance:	Unknown
	Accuracy:	Unknown

System Power Supply

---

	Location:	To Be Filled By O.E.M.
	Device Name:	To Be Filled By O.E.M.
	Manufacturer:	To Be Filled By O.E.M.
	Serial Number:	To Be Filled By O.E.M.
	Asset Tag Number:	To Be Filled By O.E.M.
	Model Part Number:	To Be Filled By O.E.M.
	Revision Level:	To Be Filled By O.E.M.
	Power Supply Status:	Present
	Power Supply Type:	Switching
	Power Status:	OK
	Hot replaceable:	No
	Unplugged from wall:	No

Processor Additional Information

---

	Firmware Component Name:	uCode Version
	Firmware Manufacturer:
	Firmware Version:	uCode Version
	Firmware Release Date:

TPM

---

	TPM Specification Version:	2.0
	TPM Vendor:	Intel
	TPM Description:	INTEL

Firmware Version Information

---

	Reference Code - CPU	11.1.45.32
	uCode Version	0.0.0.234
	TXT ACM version	1.14.16.0

Firmware Version Information

---

	Reference Code - ME	11.1.45.32
	MEBx version	15.0.0.2
	ME Firmware Version	Consumer SKU

Firmware Version Information

---

	Reference Code - PCH	11.1.45.32
	PCH-CRID Status	Disabled
	PCH-CRID Original Value	0x11
	PCH-CRID New Value	0x11
	OPROM - RST - RAID
	PCH Hsio Version	4.0.0.0

Firmware Version Information

---

	Reference Code - SA - System Agent	11.1.45.32
	Reference Code - MRC	0.0.0.57
	SA - PCIe Version	11.1.45.32
	SA-CRID Status	Disabled
	SA-CRID Original Value	0.0.0.3
	SA-CRID New Value	0.0.0.3
	OPROM - VBIOS
	IO Manageability Engine FW Version
	PHY Build Version
	Thunderbolt(TM) FW Version
	System Agent Manageability Engine FW Version	15.255

Firmware Version Information

---

	FSP Binary Version	4.0.0.0

L1 Cache

---

	Socket Designation:	L1 Cache
	Cache State:	Enabled
	Cache Location:	Internal
	Cache Type:	L1
	Cache Scheme:	Write-Back
	Supported SRAM Type:	Synchronous
	Current SRAM Type:	Synchronous
	Cache Speed:	Unknown
	Error Correction Type:	Parity
	Maximum Cache Size:	384 KBytes
	Installed Cache Size:	384 KBytes
	Cache Associativity:	8-way Set-Associative

L2 Cache

---

	Socket Designation:	L2 Cache
	Cache State:	Enabled
	Cache Location:	Internal
	Cache Type:	L2 Unified
	Cache Scheme:	Write-Back
	Supported SRAM Type:	Synchronous
	Current SRAM Type:	Synchronous
	Cache Speed:	Unknown
	Error Correction Type:	Single-bit ECC
	Maximum Cache Size:	1536 KBytes
	Installed Cache Size:	1536 KBytes
	Cache Associativity:	4-way Set-Associative

L3 Cache

---

	Socket Designation:	L3 Cache
	Cache State:	Enabled
	Cache Location:	Internal
	Cache Type:	L3 Unified
	Cache Scheme:	Write-Back
	Supported SRAM Type:	Synchronous
	Current SRAM Type:	Synchronous
	Cache Speed:	Unknown
	Error Correction Type:	Multi-bit ECC
	Maximum Cache Size:	12288 KBytes
	Installed Cache Size:	12288 KBytes
	Cache Associativity:	16-way Set-Associative

Processor

---

	Processor Manufacturer:	Intel(R) Corporation
	Processor Version:	Intel(R) Core(TM) i5-10400F CPU @ 2.90GHz
	External Clock:	100 MHz
	Maximum Clock Supported:	4300 MHz
	Current Clock:	2673 MHz
	CPU Socket:	Populated
	CPU Status:	Enabled
	Processor Type:	Central Processor
	Processor Voltage:	0.8 V
	Processor Upgrade:	Unknown (1)
	Socket Designation:	U3E1

Intel vPro

---

	CPU VT-x Support:	Supported
	CPU VT-x Status:	Enabled
	CPU VT-x2 Support:	Not Supported
	CPU VT-x2 Status:	Disabled
	CPU TXT Support:	Not Supported
	CPU TXT Status:	Disabled
	CPU VMX Status:	Enabled
	CPU SMX Status:	Disabled
	Intel ME Status:	Enabled
	Intel OST Firmware Support:	Not Supported
	Intel ASF Firmware Support:	Not Supported
	Intel AMT Pro Firmware Support:	Not Supported
	Intel AMT Basic Firmware Support:	Not Supported
	Intel TPM Firmware Support:	Not Supported
	Intel Castle Peak Support:	Not Supported
	Intel WoX Support:	Not Supported
	Intel Virtualization Engine Support:	Not Supported
	Intel Anti-Theft Technology Support:	Not Supported
	TPM On-board:	Not Supported
	Intel Anti-Theft Technology Enrolled:	Not Supported
	Intel ME Version:	v15.0, Build 1622, Hotfix 22
	BIOS VT-x Support:	Not Supported
	BIOS VT-d Support:	Supported
	BIOS TXT Support:	Not Supported
	BIOS TPM Support:	Not Supported
	BIOS ME Support:	Not Supported
	BIOS VA Extensions Support:	Supported
	Intel AT PBA For Recovery Support:	Not Supported
	Intel AT WWAN Support:	Not Supported

On Board Device

---

	Device Description:	Onboard - Other
	Device Type:	Unknown
	Device Status:	Enabled

On Board Device

---

	Device Description:	Onboard - Other
	Device Type:	Unknown
	Device Status:	Enabled

On Board Device

---

	Device Description:	Onboard - Other
	Device Type:	Unknown
	Device Status:	Enabled

On Board Device

---

	Device Description:	Onboard - Other
	Device Type:	Unknown
	Device Status:	Enabled

On Board Device

---

	Device Description:	Onboard - SATA
	Device Type:	SATA Controller
	Device Status:	Enabled

On Board Device

---

	Device Description:	Onboard - Other
	Device Type:	Unknown
	Device Status:	Enabled

On Board Device

---

	Device Description:	Onboard - Sound
	Device Type:	Audio Device
	Device Status:	Enabled

On Board Device

---

	Device Description:	Onboard - Other
	Device Type:	Unknown
	Device Status:	Enabled

On Board Device

---

	Device Description:	Onboard - Other
	Device Type:	Unknown
	Device Status:	Enabled

Firmware Version Information

---

	Lan Phy Version
	Sensor Firmware Version
	Debug Mode Status	Disabled
	Performance Mode Status	Disabled
	Debug Use USB(Disabled:Serial)	Disabled
	ICC Overclocking Version	0.0.0.0
	UNDI Version
	EC FW Version	0.0
	GOP Version	0.9.0.4369
	Royal Park Version
	Platform Version	0.7.0.0

System Boot Information

---

	Boot Status:	No error occurred

BIOS Language

---

		en|US|iso8859-1 <Active>
		zh|TW|unicode
		zh|CN|unicode
		ru|RU|iso8859-5
		de|DE|iso8859-1
		ja|JP|unicode
		ko|KR|unicode
		es|ES|iso8859-1
		fr|FR|iso8859-1
		pt|PT|iso8859-1
		vi|VI|iso8859-1
		id|ID|iso8859-1
		tr|TR|iso8859-1
		pl|PL|iso8859-1

Group Associations

---

Group Associations

---

Memory Devices

---

Physical Memory Array

---

	Array Location:	System board
	Array Use:	System memory
	Error Detecting Method:	None
	Memory Capacity:	32 GBytes
	Memory Devices:	2

Memory Array Mapped Address

---

	Starting Address:	00000000
	Ending Address:	01FFFFFF
	Partition Width:	2

Memory Device

---

	Total Width:	64 bits
	Data Width:	64 bits
	Device Size:	16384 MBytes
	Device Form Factor:	DIMM
	Device Locator:	Controller0-ChannelA
	Bank Locator:	BANK 0
	Device Type:	DDR4
	Device Type Detail:	Synchronous
	Memory Speed:	2666 MT/s
	Configured Memory Speed:	2666 MT/s
	Manufacturer:	Kingston
	Serial Number:	E81B6EF1
	Part Number:	9905743-220.A00G
	Asset Tag:	9876543210
	Volatile Size:	16 GBytes

Memory Device

---

	Total Width:	64 bits
	Data Width:	64 bits
	Device Size:	16384 MBytes
	Device Form Factor:	DIMM
	Device Locator:	Controller0-ChannelB
	Bank Locator:	BANK 1
	Device Type:	DDR4
	Device Type Detail:	Synchronous
	Memory Speed:	2666 MT/s
	Configured Memory Speed:	2666 MT/s
	Manufacturer:	Kingston
	Serial Number:	7121729D
	Part Number:	9905743-220.A00G
	Asset Tag:	9876543210
	Volatile Size:	16 GBytes

Memory Device Mapped Address

---

	Starting Address:	00000000
	Ending Address:	00FFFFFF
	Partition Row Position:	Unknown
	Interleave Position:	1
	Interleave Data Depth:	1

Memory Device Mapped Address

---

	Starting Address:	01000000
	Ending Address:	01FFFFFF
	Partition Row Position:	Unknown
	Interleave Position:	2
	Interleave Data Depth:	1

Port Connectors

---

Mouse Port

---

	Port Type:	Mouse Port
	Internal Reference:	J1A1
	Internal Connector Type:	None
	External Reference:	PS2Mouse
	External Connector Type:	PS/2

Keyboard Port

---

	Port Type:	Keyboard Port
	Internal Reference:	J1A1
	Internal Connector Type:	None
	External Reference:	Keyboard
	External Connector Type:	PS/2

Port Connector

---

	Port Type:	Unknown
	Internal Reference:	J2A1
	Internal Connector Type:	None
	External Reference:	TV Out
	External Connector Type:	Mini-Centronics Type-14

Serial Port 16550A Compatible

---

	Port Type:	Serial Port 16550A Compatible
	Internal Reference:	J2A2A
	Internal Connector Type:	None
	External Reference:	COM A
	External Connector Type:	DB-9 pin male

Video Port

---

	Port Type:	Video Port
	Internal Reference:	J2A2B
	Internal Connector Type:	None
	External Reference:	Video
	External Connector Type:	DB-15 pin female

USB

---

	Port Type:	USB
	Internal Reference:	J3A1
	Internal Connector Type:	None
	External Reference:	USB1
	External Connector Type:	Access Bus (USB)

USB

---

	Port Type:	USB
	Internal Reference:	J3A1
	Internal Connector Type:	None
	External Reference:	USB2
	External Connector Type:	Access Bus (USB)

USB

---

	Port Type:	USB
	Internal Reference:	J3A1
	Internal Connector Type:	None
	External Reference:	USB3
	External Connector Type:	Access Bus (USB)

Port Connector

---

	Port Type:	Unknown
	Internal Reference:	J9A1 - TPM HDR
	Internal Connector Type:	Unknown
	External Reference:
	External Connector Type:	None

Port Connector

---

	Port Type:	Unknown
	Internal Reference:	J9C1 - PCIE DOCKING CONN
	Internal Connector Type:	Unknown
	External Reference:
	External Connector Type:	None

Port Connector

---

	Port Type:	Unknown
	Internal Reference:	J2B3 - CPU FAN
	Internal Connector Type:	Unknown
	External Reference:
	External Connector Type:	None

Port Connector

---

	Port Type:	Unknown
	Internal Reference:	J6C2 - EXT HDMI
	Internal Connector Type:	Unknown
	External Reference:
	External Connector Type:	None

Port Connector

---

	Port Type:	Unknown
	Internal Reference:	J3C1 - GMCH FAN
	Internal Connector Type:	Unknown
	External Reference:
	External Connector Type:	None

Port Connector

---

	Port Type:	Unknown
	Internal Reference:	J1D1 - ITP
	Internal Connector Type:	Unknown
	External Reference:
	External Connector Type:	None

Port Connector

---

	Port Type:	Unknown
	Internal Reference:	J9E2 - MDC INTPSR
	Internal Connector Type:	Unknown
	External Reference:
	External Connector Type:	None

Port Connector

---

	Port Type:	Unknown
	Internal Reference:	J9E4 - MDC INTPSR
	Internal Connector Type:	Unknown
	External Reference:
	External Connector Type:	None

Port Connector

---

	Port Type:	Unknown
	Internal Reference:	J9E3 - LPC HOT DOCKING
	Internal Connector Type:	Unknown
	External Reference:
	External Connector Type:	None

Port Connector

---

	Port Type:	Unknown
	Internal Reference:	J9E1 - SCAN MATRIX
	Internal Connector Type:	Unknown
	External Reference:
	External Connector Type:	None

Port Connector

---

	Port Type:	Unknown
	Internal Reference:	J9G1 - LPC SIDE BAND
	Internal Connector Type:	Unknown
	External Reference:
	External Connector Type:	None

Port Connector

---

	Port Type:	Unknown
	Internal Reference:	J8F1 - UNIFIED
	Internal Connector Type:	Unknown
	External Reference:
	External Connector Type:	None

Port Connector

---

	Port Type:	Unknown
	Internal Reference:	J6F1 - LVDS
	Internal Connector Type:	Unknown
	External Reference:
	External Connector Type:	None

Port Connector

---

	Port Type:	Unknown
	Internal Reference:	J2F1 - LAI FAN
	Internal Connector Type:	Unknown
	External Reference:
	External Connector Type:	None

Port Connector

---

	Port Type:	Unknown
	Internal Reference:	J2G1 - GFX VID
	Internal Connector Type:	Unknown
	External Reference:
	External Connector Type:	None

Port Connector

---

	Port Type:	Unknown
	Internal Reference:	J1G6 - AC JACK
	Internal Connector Type:	Unknown
	External Reference:
	External Connector Type:	None

Keyboard Port

---

	Port Type:	Keyboard Port
	Internal Reference:	None
	Internal Connector Type:	None
	External Reference:	Keyboard
	External Connector Type:	PS/2

Mouse Port

---

	Port Type:	Mouse Port
	Internal Reference:	None
	Internal Connector Type:	None
	External Reference:	Mouse
	External Connector Type:	PS/2

Serial Port 16550A Compatible

---

	Port Type:	Serial Port 16550A Compatible
	Internal Reference:	None
	Internal Connector Type:	Unknown
	External Reference:	COM 1
	External Connector Type:	None

Video Port

---

	Port Type:	Video Port
	Internal Reference:	J1A2B
	Internal Connector Type:	Unknown
	External Reference:	Video
	External Connector Type:	DB-15 pin female

Video Port

---

	Port Type:	Video Port
	Internal Reference:	J3A2
	Internal Connector Type:	Unknown
	External Reference:	HDMI
	External Connector Type:	None

USB

---

	Port Type:	USB
	Internal Reference:	None
	Internal Connector Type:	None
	External Reference:	USB1.1 - 1#
	External Connector Type:	Access Bus (USB)

USB

---

	Port Type:	USB
	Internal Reference:	None
	Internal Connector Type:	None
	External Reference:	USB1.1 - 2#
	External Connector Type:	Access Bus (USB)

USB

---

	Port Type:	USB
	Internal Reference:	None
	Internal Connector Type:	None
	External Reference:	USB1.1 - 3#
	External Connector Type:	Access Bus (USB)

USB

---

	Port Type:	USB
	Internal Reference:	None
	Internal Connector Type:	None
	External Reference:	USB1.1 - 4#
	External Connector Type:	Access Bus (USB)

USB

---

	Port Type:	USB
	Internal Reference:	None
	Internal Connector Type:	None
	External Reference:	USB1.1 - 5#
	External Connector Type:	Access Bus (USB)

USB

---

	Port Type:	USB
	Internal Reference:	None
	Internal Connector Type:	None
	External Reference:	USB2.0 - 1#
	External Connector Type:	Access Bus (USB)

USB

---

	Port Type:	USB
	Internal Reference:	None
	Internal Connector Type:	None
	External Reference:	USB2.0 - 2#
	External Connector Type:	Access Bus (USB)

Network Port

---

	Port Type:	Network Port
	Internal Reference:	None
	Internal Connector Type:	None
	External Reference:	Ethernet
	External Connector Type:	RJ-45

SATA

---

	Port Type:	SATA
	Internal Reference:	J8J1
	Internal Connector Type:	None
	External Reference:	SATA Port 0 Direct Connect
	External Connector Type:	SAS/SATA Plug Receptacle

SATA

---

	Port Type:	SATA
	Internal Reference:	J7J1
	Internal Connector Type:	None
	External Reference:	eSATA Port 4
	External Connector Type:	SAS/SATA Plug Receptacle

SATA

---

	Port Type:	SATA
	Internal Reference:	J6J1
	Internal Connector Type:	None
	External Reference:	eSATA Port 3
	External Connector Type:	SAS/SATA Plug Receptacle

SATA

---

	Port Type:	SATA
	Internal Reference:	J7G1 - SATA Port 2
	Internal Connector Type:	SAS/SATA Plug Receptacle
	External Reference:	None
	External Connector Type:	None

SATA

---

	Port Type:	SATA
	Internal Reference:	J7G2 - SATA Port 1
	Internal Connector Type:	SAS/SATA Plug Receptacle
	External Reference:	None
	External Connector Type:	None

Port Connector

---

	Port Type:	Unknown
	Internal Reference:	J1F2
	Internal Connector Type:	None
	External Reference:	AC IN
	External Connector Type:	Unknown

Port Connector

---

	Port Type:	Unknown
	Internal Reference:	J5B1 - PCH JTAG
	Internal Connector Type:	Unknown
	External Reference:	None
	External Connector Type:	None

Port Connector

---

	Port Type:	Unknown
	Internal Reference:	J9A1 - TPM/PORT 80
	Internal Connector Type:	Unknown
	External Reference:	None
	External Connector Type:	None

Port Connector

---

	Port Type:	Unknown
	Internal Reference:	J9E4 - HDA 2X8 Header
	Internal Connector Type:	Unknown
	External Reference:	None
	External Connector Type:	None

Port Connector

---

	Port Type:	Unknown
	Internal Reference:	J9E7 - HDA 8Pin Header
	Internal Connector Type:	Unknown
	External Reference:	None
	External Connector Type:	None

Port Connector

---

	Port Type:	Unknown
	Internal Reference:	J8F1 - HDA HDMI
	Internal Connector Type:	Unknown
	External Reference:	None
	External Connector Type:	None

Port Connector

---

	Port Type:	Unknown
	Internal Reference:	J9E3 - Scan Matrix Keyboard
	Internal Connector Type:	Unknown
	External Reference:	None
	External Connector Type:	None

Port Connector

---

	Port Type:	Unknown
	Internal Reference:	J8E1 - SPI Program
	Internal Connector Type:	Unknown
	External Reference:	None
	External Connector Type:	None

Port Connector

---

	Port Type:	Unknown
	Internal Reference:	J9E5 - LPC Hot Docking
	Internal Connector Type:	Unknown
	External Reference:	None
	External Connector Type:	None

Port Connector

---

	Port Type:	Unknown
	Internal Reference:	J9G2 - LPC SIDE BAND
	Internal Connector Type:	Unknown
	External Reference:	None
	External Connector Type:	None

Port Connector

---

	Port Type:	Unknown
	Internal Reference:	J8F2 - LPC Slot
	Internal Connector Type:	Unknown
	External Reference:	None
	External Connector Type:	None

Port Connector

---

	Port Type:	Unknown
	Internal Reference:	J8H3 - PCH XDP
	Internal Connector Type:	Unknown
	External Reference:	None
	External Connector Type:	None

Port Connector

---

	Port Type:	Unknown
	Internal Reference:	J6H1 - SATA Power
	Internal Connector Type:	Unknown
	External Reference:	None
	External Connector Type:	None

Port Connector

---

	Port Type:	Unknown
	Internal Reference:	J5J1 - FP Header
	Internal Connector Type:	Unknown
	External Reference:	None
	External Connector Type:	None

Port Connector

---

	Port Type:	Unknown
	Internal Reference:	J4H1 - ATX Power
	Internal Connector Type:	Unknown
	External Reference:	None
	External Connector Type:	None

Port Connector

---

	Port Type:	Unknown
	Internal Reference:	J1J3 - AVMC
	Internal Connector Type:	Unknown
	External Reference:	None
	External Connector Type:	None

Port Connector

---

	Port Type:	Unknown
	Internal Reference:	J1H1 - BATT B
	Internal Connector Type:	Unknown
	External Reference:	None
	External Connector Type:	None

Port Connector

---

	Port Type:	Unknown
	Internal Reference:	J1H2 - BATT A
	Internal Connector Type:	Unknown
	External Reference:	None
	External Connector Type:	None

Port Connector

---

	Port Type:	Unknown
	Internal Reference:	J2G1 - CPU Fan
	Internal Connector Type:	Unknown
	External Reference:	None
	External Connector Type:	None

Port Connector

---

	Port Type:	Unknown
	Internal Reference:	J1D3 - XDP
	Internal Connector Type:	Unknown
	External Reference:	None
	External Connector Type:	None

Port Connector

---

	Port Type:	Unknown
	Internal Reference:	J4V1 - Memory Slot 1
	Internal Connector Type:	Unknown
	External Reference:	None
	External Connector Type:	None

Port Connector

---

	Port Type:	Unknown
	Internal Reference:	J4V2 - Memory Slot 2
	Internal Connector Type:	Unknown
	External Reference:	None
	External Connector Type:	None

Port Connector

---

	Port Type:	Unknown
	Internal Reference:	J4C1 - FAN PWR
	Internal Connector Type:	Unknown
	External Reference:	None
	External Connector Type:	None

System Slots

---

J6B2

---

	Slot Designation:	J6B2
	Slot Type:	PCI Express
	Slot Usage:	In use
	Slot Data Bus Width:	16x / x16
	Slot Length:	Long
	Base Segment:Bus:Device:Function Number:	00:1:0

J6B1

---

	Slot Designation:	J6B1
	Slot Type:	PCI Express
	Slot Usage:	In use
	Slot Data Bus Width:	1x / x1
	Slot Length:	Short
	Base Segment:Bus:Device:Function Number:	00:28:3

J6D1

---

	Slot Designation:	J6D1
	Slot Type:	PCI Express
	Slot Usage:	In use
	Slot Data Bus Width:	1x / x1
	Slot Length:	Short
	Base Segment:Bus:Device:Function Number:	00:28:4

J7B1

---

	Slot Designation:	J7B1
	Slot Type:	PCI Express
	Slot Usage:	In use
	Slot Data Bus Width:	1x / x1
	Slot Length:	Short
	Base Segment:Bus:Device:Function Number:	00:28:5

J8B4

---

	Slot Designation:	J8B4
	Slot Type:	PCI Express
	Slot Usage:	In use
	Slot Data Bus Width:	1x / x1
	Slot Length:	Short
	Base Segment:Bus:Device:Function Number:	00:28:6

Intel ME

---

[Intel Manageability Engine Features]
	Intel ME Version:	15.0, Build 1622, Hot Fix 22
	Intel ME Recovery Image Version:	15.0, Build 1622, Hot Fix 22
	Intel ME FITC Version:	15.0, Build 1622, Hot Fix 22
[ME Firmware Capabilities]
	Full Network Manageability:	Not Capable
	Standard Network Manageability:	Not Capable
	Manageability (AMT):	Not Capable
	Small Business Advantage:	Not Capable
	Intel Integrated Touch:	Not Capable
	Intel Anti-Theft:	Not Capable
	Capability Licensing Service:	Not Capable
	Virtualization Engine:	Not Capable
	Intel Sensor Hub (ISH):	Not Capable
	ICC Over Clocking:	Not Capable
	Protected Audio Video Path (PAVP):	Capable
	Network Frame Forwarder (NFF):	Not Capable
	Remote PC Assist (RPAT):	Capable
	IPV6:	Not Capable
	KVM Remote Control:	Not Capable
	Outbreak Containment Heuristic (OCH):	Not Capable
	Dynamic Application Loader (DAL):	Capable
	Cipher Transport Layer (TLS):	Capable
	Wireless LAN (WLAN):	Not Capable
	Platform Trust Technology (PTT):	Capable
	Near Field Communication (NFC):	Not Capable
[ME Firmware Feature State]
	Full Network Manageability:	Disabled
	Standard Network Manageability:	Disabled
	Manageability (AMT):	Disabled
	Small Business Advantage:	Not Capable
	MEI3:	Not Capable
	Intel Anti-Theft:	Disabled
	Capability Licensing Service:	Disabled
	Virtualization Engine:	Disabled
	Intel Sensor Hub (ISH):	Disabled
	ICC Over Clocking:	Disabled
	Protected Audio Video Path (PAVP):	Enabled
	Network Frame Forwarder (NFF):	Not Capable
	Remote PC Assist (RPAT):	Enabled
	IPV6:	Disabled
	KVM Remote Control:	Disabled
	Outbreak Containment Heuristic (OCH):	Disabled
	Dynamic Application Loader (DAL):	Capable
	Cipher Transport Layer (TLS):	Enabled
	Wireless LAN (WLAN):	Disabled
	Platform Trust Technology (PTT):	Enabled
	Near Field Communication (NFC):	Disabled
[ME Firmware Platform Type]
	Platform Target Usage Type:	Desktop
	SKU:	Regular SKU
	ME Firmware Image Type:	Consumer SKU Firmware
	Platform Brand:	None
	Host ME Region Flash Protection Override (HMRFPO) Status:	Locked

Memory

---

[General Information]
	Total Memory Size:	32 GBytes
	Total Memory Size [MB]:	32768
[Current Performance Settings]
	Maximum Supported Memory Clock:	1333.3 MHz
	Current Memory Clock:	1330.1 MHz
	Current Timing (tCAS-tRCD-tRP-tRAS):	22-22-22-52
	Memory Channels Supported:	2
	Memory Channels Active:	2
	Command Rate (CR):	2T
	Read to Read Delay (tRDRD_SG/TrdrdScL) Same Bank Group:	7T
	Read to Read Delay (tRDRD_DG/TrdrdScDlr) Different Bank Group:	4T
	Read to Read Delay (tRDRD_SD) Same DIMM:	6T
	Read to Read Delay (tRDRD_DD) Different DIMM:	7T
	Write to Write Delay (tWRWR_SG/TwrwrScL) Same Bank Group:	7T
	Write to Write Delay (tWRWR_DG/TwrwrScDlr) Different Bank Group:	4T
	Write to Write Delay (tWRWR_SD) Same DIMM:	7T
	Write to Write Delay (tWRWR_DD) Different DIMM:	7T
	Read to Write Delay (tRDWR_SG/TrdwrScL) Same Bank Group:	12T
	Read to Write Delay (tRDWR_DG/TrdwrScDlr) Different Bank Group:	12T
	Read to Write Delay (tRDWR_SD) Same DIMM:	13T
	Read to Write Delay (tRDWR_DD) Different DIMM:	14T
	Write to Read Delay (tWRRD_SG/TwrrdScL) Same Bank Group:	33T
	Write to Read Delay (tWRRD_DG/TwrrdScDlr) Different Bank Group:	27T
	Write to Read Delay (tWRRD_SD) Same DIMM:	4T
	Write to Read Delay (tWRRD_DD) Different DIMM:	4T
	Read to Precharge Delay (tRTP):	10T
	Write to Precharge Delay (tWTP):	32T
	Write Recovery Time (tWR):	21T
	RAS# to RAS# Delay (tRRD_L):	8T
	RAS# to RAS# Delay (tRRD_S):	18T
	Row Cycle Time (tRC):	74T
	Refresh Cycle Time (tRFC):	560T
	Four Activate Window (tFAW):	34T

Row: 0 [BANK 0/Controller0-ChannelA] - 16 GB PC4-25600 DDR4 SDRAM Kingston 9905743-220.A00G

---

[General Module Information]
	Module Number:	0
	Module Size:	16 GBytes
	Memory Type:	DDR4 SDRAM
	Module Type:	Unbuffered DIMM (UDIMM)
	Memory Speed:	1600.0 MHz (DDR4-3200 / PC4-25600)
	Module Manufacturer:	Kingston
	Module Part Number:	9905743-220.A00G
	Module Revision:	0.0
	Module Serial Number:	4050525160 (E81B6EF1)
	Module Manufacturing Date:	Year: 2023, Week: 40
	Module Manufacturing Location:	5
	SDRAM Manufacturer:	Samsung
	DRAM Steppping:	4.2
	Error Check/Correction:	None
[Module Characteristics]
	Row Address Bits:	17
	Column Address Bits:	10
	Module Density:	16384 Mb
	Number Of Ranks:	1
	Number Of Bank Groups:	4
	Device Width:	8 bits
	Bus Width:	64 bits
	Die Count:	1
	Module Nominal Voltage (VDD):	1.2 V
	Minimum SDRAM Cycle Time (tCKAVGmin):	0.62500 ns (1600 MHz)
	Maximum SDRAM Cycle Time (tCKAVGmax):	1.60000 ns
	CAS# Latencies Supported:	10, 11, 12, 13, 14, 15, 16, 17, 18, 19, 20, 21, 22
	Minimum CAS# Latency Time (tAAmin):	13.750 ns
	Minimum RAS# to CAS# Delay (tRCDmin):	13.750 ns
	Minimum Row Precharge Time (tRPmin):	13.750 ns
	Minimum Active to Precharge Time (tRASmin):	32.000 ns
	Supported Module Timing at 1600.0 MHz:	22-22-22-52
	Supported Module Timing at 1466.7 MHz:	21-21-21-47
	Supported Module Timing at 1333.3 MHz:	19-19-19-43
	Supported Module Timing at 1200.0 MHz:	17-17-17-39
	Supported Module Timing at 1066.7 MHz:	15-15-15-35
	Supported Module Timing at 933.3 MHz:	13-13-13-30
	Supported Module Timing at 800.0 MHz:	11-11-11-26
	Supported Module Timing at 666.7 MHz:	10-10-10-22
	Minimum Active to Active/Refresh Time (tRCmin):	45.750 ns
	Minimum Refresh Recovery Time Delay (tRFC1min):	350.000 ns
	Minimum Refresh Recovery Time Delay (tRFC2min):	260.000 ns
	Minimum Refresh Recovery Time Delay (tRFC4min):	160.000 ns
	Minimum Four Activate Window Delay Time (tFAWmin):	21.000 ns
	Minimum Active to Active Delay Time - Different Bank Group (tRRD_Smin):	2.500 ns
	Minimum Active to Active Delay Time - Same Bank Group (tRRD_Lmin):	4.900 ns
	Minimum CAS to CAS Delay Time - Same Bank Group (tCCD_Lmin):	5.000 ns
[Features]
	Module Temperature Sensor (TSOD):	Not Supported
	Module Nominal Height:	31 - 32 mm
	Module Maximum Thickness (Front):	1 - 2 mm
	Module Maximum Thickness (Back):	1 - 2 mm
	Address Mapping from Edge Connector to DRAM:	Standard

Row: 2 [BANK 1/Controller0-ChannelB] - 16 GB PC4-25600 DDR4 SDRAM Kingston 9905743-220.A00G

---

[General Module Information]
	Module Number:	2
	Module Size:	16 GBytes
	Memory Type:	DDR4 SDRAM
	Module Type:	Unbuffered DIMM (UDIMM)
	Memory Speed:	1600.0 MHz (DDR4-3200 / PC4-25600)
	Module Manufacturer:	Kingston
	Module Part Number:	9905743-220.A00G
	Module Revision:	0.0
	Module Serial Number:	2641502577 (7121729D)
	Module Manufacturing Date:	Year: 2023, Week: 40
	Module Manufacturing Location:	5
	SDRAM Manufacturer:	Samsung
	DRAM Steppping:	4.2
	Error Check/Correction:	None
[Module Characteristics]
	Row Address Bits:	17
	Column Address Bits:	10
	Module Density:	16384 Mb
	Number Of Ranks:	1
	Number Of Bank Groups:	4
	Device Width:	8 bits
	Bus Width:	64 bits
	Die Count:	1
	Module Nominal Voltage (VDD):	1.2 V
	Minimum SDRAM Cycle Time (tCKAVGmin):	0.62500 ns (1600 MHz)
	Maximum SDRAM Cycle Time (tCKAVGmax):	1.60000 ns
	CAS# Latencies Supported:	10, 11, 12, 13, 14, 15, 16, 17, 18, 19, 20, 21, 22
	Minimum CAS# Latency Time (tAAmin):	13.750 ns
	Minimum RAS# to CAS# Delay (tRCDmin):	13.750 ns
	Minimum Row Precharge Time (tRPmin):	13.750 ns
	Minimum Active to Precharge Time (tRASmin):	32.000 ns
	Supported Module Timing at 1600.0 MHz:	22-22-22-52
	Supported Module Timing at 1466.7 MHz:	21-21-21-47
	Supported Module Timing at 1333.3 MHz:	19-19-19-43
	Supported Module Timing at 1200.0 MHz:	17-17-17-39
	Supported Module Timing at 1066.7 MHz:	15-15-15-35
	Supported Module Timing at 933.3 MHz:	13-13-13-30
	Supported Module Timing at 800.0 MHz:	11-11-11-26
	Supported Module Timing at 666.7 MHz:	10-10-10-22
	Minimum Active to Active/Refresh Time (tRCmin):	45.750 ns
	Minimum Refresh Recovery Time Delay (tRFC1min):	350.000 ns
	Minimum Refresh Recovery Time Delay (tRFC2min):	260.000 ns
	Minimum Refresh Recovery Time Delay (tRFC4min):	160.000 ns
	Minimum Four Activate Window Delay Time (tFAWmin):	21.000 ns
	Minimum Active to Active Delay Time - Different Bank Group (tRRD_Smin):	2.500 ns
	Minimum Active to Active Delay Time - Same Bank Group (tRRD_Lmin):	4.900 ns
	Minimum CAS to CAS Delay Time - Same Bank Group (tCCD_Lmin):	5.000 ns
[Features]
	Module Temperature Sensor (TSOD):	Not Supported
	Module Nominal Height:	31 - 32 mm
	Module Maximum Thickness (Front):	1 - 2 mm
	Module Maximum Thickness (Back):	1 - 2 mm
	Address Mapping from Edge Connector to DRAM:	Standard

Video Adapter

---

NVIDIA GeForce RTX 3060

---

[Video Chipset]
	Video Chipset:	NVIDIA GeForce RTX 3060
	Video Chipset Codename:	GA106-302 (LHR)
	Video Memory:	12288 MBytes of GDDR6 SDRAM [Hynix]
[Video Card]
	Video Card:	Colorful RTX 3060
	Video Bus:	PCIe v4.0 x16 (16.0 GT/s) @ x16 (8.0 GT/s)
	GPU Type:	Discrete
	Video RAMDAC:	Integrated RAMDAC
	Video BIOS Version:	94.06.2f.00.62 [UEFI]
	Video Chipset Revision:	A1
[Performance]
	Graphics Processor Clock:	1777.0 MHz
	Video Unit Clock:	1560.0 MHz
	Graphics Memory Clock:	1875.2 MHz (Effective 15002.0 MHz)
	Graphics Memory Bus Width:	192-bit
	Number Of ROPs:	48
	Number Of Unified Shaders:	3584
	Number Of Ray Tracing Cores:	28
	Number Of Tensor Cores:	112
	Number Of TMUs (Texture Mapping Units):	112
	ASIC Manufacturer:	Samsung
	ASIC Serial Number:	172215905732
	NVIDIA SLI Status:	Not Present
	Resizable BAR (ReBAR) Support:	Supported
	Resizable BAR (ReBAR) State:	Disabled (256 MB)
	Hardware ID:	PCI\VEN_10DE&DEV_2504&SUBSYS_20007377&REV_A1
	PCI Location (Bus:Dev:Fnc):	1:00:0
[Driver Information]
	Driver Manufacturer:	NVIDIA
	Driver Description:	NVIDIA GeForce RTX 3060
	Driver Provider:	NVIDIA
	Driver Version:	32.0.15.7283 (GeForce 572.83)
	Driver Date:	14-Mar-2025
	DCH/UWD Driver:	Capable
	DeviceInstanceId	PCI\VEN_10DE&DEV_2504&SUBSYS_20007377&REV_A1\4&35E0AEB3&0&0008
	Location Paths	PCIROOT(0)#PCI(0100)#PCI(0000)

Monitor

---

DELL [Unknown Model: DELF049]

---

[General Information]
	Monitor Name:	DELL [Unknown Model: DELF049]
	Monitor Name (Manuf):	DELL P1914S
	Serial Number:	6WMM761AAEHL
	Date Of Manufacture:	Week: 3, Year: 2016
	Monitor Hardware ID:	Monitor\DELF049
	Max. Vertical Size:	30 cm
	Max. Horizontal Size:	38 cm
	Horizontal Frequency:	30 - 81 kHz
	Vertical Frequency:	56 - 76 Hz
	Maximum Pixel Clock:	140 MHz
[Advanced parameters]
	Input Signal:	Digital
	Color Bit Depth:	8 Bits per Primary Color
	Digital Video Interface Standard Supported:	DisplayPort
	Gamma Factor:	2.20
[DPMS Modes]
	Standby:	Not Supported
	Suspend:	Not Supported
	Active Off:	Supported
	Standard Colour Space (sRGB) Default:	Not Supported
	Preferred Timing Mode:	Supported
	Default GTF (Continuous Frequency):	Not Supported
	DFP 1.x Compatible:	Yes
[Supported Video Modes]
	1152 x 864	75 Hz
	1280 x 1024	60 Hz
	1280 x 1024	376 x 301 mm, Pixel Clock 108.00 MHz
[Driver Information]
	Driver Manufacturer:	Microsoft
	Driver Description:	Generic PnP Monitor
	Driver Provider:	Microsoft
	Driver Version:	10.0.19041.4355
	Driver Date:	21-Jun-2006
	DeviceInstanceId	DISPLAY\DELF049\5&A513024&2&UID4355

ViewSonic [Unknown Model: VSC2E3F]

---

[General Information]
	Monitor Name:	ViewSonic [Unknown Model: VSC2E3F]
	Monitor Name (Manuf):	VX2479 Series
	Serial Number:	X9N234100920
	Date Of Manufacture:	Week: 41, Year: 2023
	Monitor Hardware ID:	Monitor\VSC2E3F
	Max. Vertical Size:	29 cm
	Max. Horizontal Size:	53 cm
	Horizontal Frequency:	183 - 183 kHz
	Vertical Frequency:	48 - 165 Hz
	Maximum Pixel Clock:	380 MHz
[Advanced parameters]
	Input Signal:	Digital
	Color Bit Depth:	10 Bits per Primary Color
	Digital Video Interface Standard Supported:	DisplayPort
	Gamma Factor:	2.20
[DPMS Modes]
	Standby:	Not Supported
	Suspend:	Not Supported
	Active Off:	Supported
	Standard Colour Space (sRGB) Default:	Supported
	Preferred Timing Mode:	Supported
	Default GTF (Continuous Frequency):	Supported
	DFP 1.x Compatible:	Yes
[Supported Video Modes]
	1680 x 1050	60 Hz
	1600 x 1200	60 Hz
	1600 x 900	60 Hz
	1440 x 900	60 Hz
	1400 x 1050	60 Hz
	1280 x 1024	60 Hz
	1280 x 960	60 Hz
	1280 x 720	60 Hz
	1920 x 1080	527 x 296 mm, Pixel Clock 148.50 MHz
[Driver Information]
	Driver Manufacturer:	ViewSonic
	Driver Description:	ViewSonic VX2479-HD-PRO
	Driver Provider:	ViewSonic
	Driver Version:	1.0.0.0
	Driver Date:	23-Jul-2023
	DeviceInstanceId	DISPLAY\VSC2E3F\5&A513024&2&UID4357

Drives

---

(S)ATA/ATAPI Drives

---

WDC WD5000AAKX-001CA0

---

[General Information]
	Drive Controller:	Serial ATA 6Gb/s @ 6Gb/s
	Host Controller:	Intel Tiger Lake PCH-H - SATA Controller (AHCI) [B1]
	Drive Model:	WDC WD5000AAKX-001CA0
	Drive Firmware Revision:	15.01H15
	Drive Serial Number:	WD-WCAYUU357490
	World Wide Name:	50014EE25B3CCD9E
	Drive Capacity:	476,940 MBytes (500 GB)
	Drive Capacity [MB]:	476940
	ATA Major Version Supported:	ATA/ATAPI-5, ATA/ATAPI-6, ATA/ATAPI-7, ATA8-ACS
	ATA Transport Version Supported:	SATA 3.0
	Drive Letter(s):	F:
[Drive Geometry]
	Number of Cylinders:	16383
	Number of Heads:	16
	Sectors Per Track:	63
	Number Of ECC Bytes:	50
	Number of Sectors:	16514064
	Total 48-bit LBA Sectors:	976773168
	Logical Sector Size:	512 Bytes
	Cache Buffer Size:	16384 KBytes
[Transfer Modes]
	Sectors Per Interrupt:	Total: 16, Active: 16
	Max. PIO Transfer Mode:	4
	Multiword DMA Mode:	Total: 2, Active: -
	Singleword DMA Mode:	Total: -, Active: -
	Ultra-DMA Mode:	Total: 6 (ATA-133), Active: 0 (?)
	Max. Multiword DMA Transfer Rate:	16.7 MBytes/s
	Max. PIO with IORDY Transfer Rate:	16.7 MBytes/s
	Max. PIO w/o IORDY Transfer Rate:	16.7 MBytes/s
	Transfer Width:	16-bit
	Native Command Queuing:	Supported, Max. Depth: 32
	TRIM Command:	Not Supported
[Device flags]
	Fixed Drive:	Present
	Removable Drive:	Not Present
	Magnetic Storage:	Present
	LBA Mode:	Supported
	DMA Mode:	Supported
	IORDY:	Supported
	IORDY Disableable:	Supported
[Features]
	Write Cache:	Present, Active
	S.M.A.R.T. Feature:	Present, Active
	Security Feature:	Present, Inactive
	Removable Media Feature:	Not Present, Disabled
	Power Management:	Present, Active
	Advanced Power Management:	Not Present, Inactive
	Packet Interface:	Not Present, Disabled
	Look-Ahead Buffer:	Present, Active
	Host Protected Area:	Present, Enabled
	Power-Up In Standby:	Supported, Inactive
	Automatic Acoustic Management:	Not Supported, Inactive
	48-bit LBA:	Supported, Active
	Host-Initiated Link Power Management (HIPM):	Supported
	Device-Initiated Link Power Management (DIPM):	Not Supported
	In-Order Data Delivery:	Not Supported
	Hardware Feature Control:	Not Supported
	Software Settings Preservation:	Supported, Enabled
	NCQ Autosense:	Not Supported
	Link Power State Device Sleep:	Not Supported
	Hybrid Information Feature:	Not Supported
	Rebuild Assist:	Not Supported
	Power Disable:	Not Supported
	Zoned Device ATA Command Set:	Not Supported
	All Write Cache Non-Volatile:	Not Supported
	Extended Number of User Addressable Sectors:	Not Supported
	CFast Specification:	Not Supported
	NCQ Priority Information:	Supported
	Host Automatic Partial to Slumber Transitions:	Not Supported
	Device Automatic Partial to Slumber Transitions:	Not Supported
	NCQ Streaming:	Not Supported
	NCQ Queue Management Command:	Not Supported
	DevSleep to Reduced Power State:	Not Supported
	Out Of Band Management Interface:	Not Supported
	Extended Power Conditions Feature:	Not Supported
	Sense Data Reporting Feature:	Not Supported
	Free-Fall Control Feature:	Not Supported
	Write-Read-Verify Feature:	Not Supported
[Security]
	Security Feature:	Supported
	Security Status:	Disabled
	Security Locked:	Disabled
	Security Frozen:	Enabled
	Enhanced Security Erase:	Supported
	Sanitize Feature:	Not Supported
	Sanitize Device - Crypto Scramble:	Not Supported
	Sanitize Device - Overwrite:	Not Supported
	Sanitize Device - Block Erase:	Not Supported
	Sanitize Device - Antifreeze Lock:	Not Supported
	Device Encrypts All User Data:	Not Supported
	Trusted Computing:	Not Supported
[Self-Monitoring, Analysis and Reporting Technology (S.M.A.R.T.)]
	[01] Raw Read Error Rate:	200/51, Worst: 200
	[03] Spin Up Time:	143/21, Worst: 139 (Data = 3816, 0)
	[04] Start/Stop Count:	72/Always OK, Worst: 72 (Data = 28945, 0)
	[05] Reallocated Sector Count:	200/140, Worst: 200
	[07] Seek Error Rate:	200/Always OK, Worst: 200
	[09] Power-on Hours/Cycle Count:	44/Always OK, Worst: 44 (40965 hours / 4.68 years)
	[0A] Spin Retry Count:	100/Always OK, Worst: 100
	[0B] Calibration Retry Count:	100/Always OK, Worst: 100
	[0C] Power Cycle Count:	86/Always OK, Worst: 86 (Data = 14687, 0)
	[C0] Power-Off Retract Count:	200/Always OK, Worst: 200 (Data = 663, 0)
	[C1] Load/Unload Cycle Count:	191/Always OK, Worst: 191 (Data = 28281, 0)
	[C2] Temperature:	102/Always OK, Worst: 91 (41.0 °C)
	[C4] Reallocation Event Count:	200/Always OK, Worst: 200
	[C5] Current Pending Sector Count:	200/Always OK, Worst: 200
	[C6] Off-Line Uncorrectable Sector Count:	200/Always OK, Worst: 200
	[C7] UltraDMA/SATA CRC Error Rate:	200/Always OK, Worst: 200
	[C8] Write/Multi-Zone Error Rate:	200/Always OK, Worst: 200

ST2000DM008-2FR102

---

[General Information]
	Drive Controller:	Serial ATA 6Gb/s @ 6Gb/s
	Host Controller:	Intel Tiger Lake PCH-H - SATA Controller (AHCI) [B1]
	Drive Model:	Seagate ST2000DM008-2FR102
	Drive Firmware Revision:	0001
	Drive Serial Number:	WFL0SGNM
	World Wide Name:	5000C500BAEDEE3F
	Drive Capacity:	1,907,729 MBytes (2000 GB)
	Drive Capacity [MB]:	1907729
	Media Rotation Rate:	7200 RPM
	Nominal Form Factor:	3.5"
	ATA Major Version Supported:	ATA/ATAPI-5, ATA/ATAPI-6, ATA/ATAPI-7, ATA8-ACS, ACS-2, ACS-3
	ATA Minor Version Supported:	ACS-3 Revision 5
	ATA Transport Version Supported:	SATA 3.1
	Drive Letter(s):	D:
[Drive Geometry]
	Number of Cylinders:	16383
	Number of Heads:	16
	Sectors Per Track:	63
	Number of Sectors:	16514064
	Total 48-bit LBA Sectors:	3907029168
	Logical Sector Size:	512 Bytes
	Cache Buffer Size:	N/A
[Transfer Modes]
	Sectors Per Interrupt:	Total: 16, Active: 16
	Max. PIO Transfer Mode:	4
	Multiword DMA Mode:	Total: 2, Active: -
	Singleword DMA Mode:	Total: -, Active: -
	Ultra-DMA Mode:	Total: 6 (ATA-133), Active: 0 (?)
	Max. Multiword DMA Transfer Rate:	16.7 MBytes/s
	Max. PIO with IORDY Transfer Rate:	16.7 MBytes/s
	Max. PIO w/o IORDY Transfer Rate:	16.7 MBytes/s
	Native Command Queuing:	Supported, Max. Depth: 32
	TRIM Command:	Supported (Indeterminate Read After TRIM)
[Device flags]
	Fixed Drive:	Present
	Removable Drive:	Not Present
	Magnetic Storage:	Present
	LBA Mode:	Supported
	DMA Mode:	Supported
	IORDY:	Supported
	IORDY Disableable:	Supported
[Features]
	Write Cache:	Present, Active
	S.M.A.R.T. Feature:	Present, Active
	Security Feature:	Present, Inactive
	Removable Media Feature:	Not Present, Disabled
	Power Management:	Present, Active
	Advanced Power Management:	Present, Active
	Packet Interface:	Not Present, Disabled
	Look-Ahead Buffer:	Present, Active
	Host Protected Area:	Present, Enabled
	Power-Up In Standby:	Supported, Inactive
	Automatic Acoustic Management:	Not Supported, Inactive
	48-bit LBA:	Supported, Active
	Host-Initiated Link Power Management (HIPM):	Supported
	Device-Initiated Link Power Management (DIPM):	Supported, Disabled
	In-Order Data Delivery:	Not Supported
	Hardware Feature Control:	Not Supported
	Software Settings Preservation:	Supported, Enabled
	NCQ Autosense:	Supported
	Link Power State Device Sleep:	Not Supported
	Hybrid Information Feature:	Not Supported
	Rebuild Assist:	Not Supported
	Power Disable:	Not Supported
	Zoned Device ATA Command Set:	Not Supported
	All Write Cache Non-Volatile:	Not Supported
	Extended Number of User Addressable Sectors:	Not Supported
	CFast Specification:	Not Supported
	NCQ Priority Information:	Not Supported
	Host Automatic Partial to Slumber Transitions:	Not Supported
	Device Automatic Partial to Slumber Transitions:	Not Supported
	NCQ Streaming:	Not Supported
	NCQ Queue Management Command:	Not Supported
	DevSleep to Reduced Power State:	Not Supported
	Out Of Band Management Interface:	Not Supported
	Extended Power Conditions Feature:	Not Supported
	Sense Data Reporting Feature:	Supported, Disabled
	Free-Fall Control Feature:	Not Supported
	Write-Read-Verify Feature:	Supported, Disabled
[Security]
	Security Feature:	Supported
	Security Status:	Disabled
	Security Locked:	Disabled
	Security Frozen:	Enabled
	Enhanced Security Erase:	Supported
	Sanitize Feature:	Not Supported
	Sanitize Device - Crypto Scramble:	Not Supported
	Sanitize Device - Overwrite:	Not Supported
	Sanitize Device - Block Erase:	Not Supported
	Sanitize Device - Antifreeze Lock:	Not Supported
	Device Encrypts All User Data:	Not Supported
	Trusted Computing:	Not Supported
[Self-Monitoring, Analysis and Reporting Technology (S.M.A.R.T.)]
	[01] Raw Read Error Rate:	82/6, Worst: 64 (Data = 172432204, 0)
	[03] Spin Up Time:	99/Always OK, Worst: 98
	[04] Start/Stop Count:	74/20, Worst: 74 (Data = 27542, 0)
	[05] Reallocated Sector Count:	100/10, Worst: 100
	[07] Seek Error Rate:	85/45, Worst: 60 (Data = 307031380, 0)
	[09] Power-on Hours/Cycle Count:	66/Always OK, Worst: 66 (30198 hours / 3.45 years)
	[0A] Spin Retry Count:	100/97, Worst: 100
	[0C] Power Cycle Count:	98/20, Worst: 98 (Data = 2649, 0)
	[B7] SATA Interface Downshift / Runtime Bad Block:	100/Always OK, Worst: 100
	[B8] End to End Error Detection Count:	100/99, Worst: 100
	[BB] Reported Uncorrectable Errors:	100/Always OK, Worst: 100
	[BC] Command Timeout Count:	100/Always OK, Worst: 100
	[BD] High Fly Writes:	100/Always OK, Worst: 100
	[BE] Airflow Temperature / Exceed Count:	63/40, Worst: 48 (37.0 °C)
	[BF] G-Sense Error Rate:	100/Always OK, Worst: 100
	[C0] Power-Off Retract Count:	100/Always OK, Worst: 100 (Data = 348, 0)
	[C1] Load/Unload Cycle Count:	1/Always OK, Worst: 1 (Data = 296982, 0)
	[C2] Temperature:	37/Always OK, Worst: 52 (37.0 °C)
	[C3] Hardware ECC Recovered:	82/Always OK, Worst: 64 (Data = 172432204, 0)
	[C5] Current Pending Sector Count:	100/Always OK, Worst: 100
	[C6] Off-Line Uncorrectable Sector Count:	100/Always OK, Worst: 100
	[C7] UltraDMA/SATA CRC Error Rate:	200/Always OK, Worst: 200
	[F0] Head Flying Hours:	100/Always OK, Worst: 253 (Data = 8346, 43805)
	[F1] Lifetime Writes from Host (LBAs Written):	100/Always OK, Worst: 253 (Data = 1974044416, 4)
	[F2] Lifetime Reads from Host (LBAs Read):	100/Always OK, Worst: 253 (Data = 595729919, 7)
[Device Statistics]
	Lifetime Power-On Resets:	2649
	Power-on Hours:	30198
	Logical Sectors Written:	19161651928
	Logical Sectors Read:	30679945630
	Number of Write Commands:	88043881
	Number of Read Commands:	252428446
	Spindle Motor Power-on Hours:	24040
	Head Flying Hours:	8282
	Head Load Events:	296982
	Number of Reallocated Logical Sectors:	0
	Read Recovery Attempts:	0
	Number of Mechanical Start Failures:	1
	Number of Reallocation Candidate Logical Sectors:	0
	Number of High Priority Unload Events:	348
	Number of Reported Uncorrectable Errors:	2
	Resets Between Command Acceptance and Completion:	0
	Current Temperature:	37 °C
	Average Short Term Temperature:	37 °C
	Average Long Term Temperature:	37 °C
	Operating Temperature Range:	13 - 55 °C
	Lifetime Temperature:	0 - 52 °C
	Lifetime Average Short Term Temperature:	32 - 47 °C
	Lifetime Average Long Term Temperature:	34 - 44 °C
	Time in Under-Temperature:	1390 minutes
	Time in Over-Temperature:	0 minutes
	Number of Hardware Resets:	17380
	Number of ASR Events:	172
	Number of Interface CRC Errors:	0

WDC WD5000LPVX-22V0TT0

---

[General Information]
	Drive Controller:	Serial ATA 6Gb/s @ 6Gb/s
	Host Controller:	Intel Tiger Lake PCH-H - SATA Controller (AHCI) [B1]
	Drive Model:	WDC WD5000LPVX-22V0TT0
	Drive Firmware Revision:	01.01A01
	Drive Serial Number:	WD-WX21EC3P1940
	World Wide Name:	50014EE6AEE5D96B
	Drive Capacity:	476,940 MBytes (500 GB)
	Drive Capacity [MB]:	476940
	Media Rotation Rate:	5400 RPM
	ATA Major Version Supported:	ATA/ATAPI-5, ATA/ATAPI-6, ATA/ATAPI-7, ATA8-ACS, ACS-2
	ATA Transport Version Supported:	SATA 3.0
	Drive Letter(s):	G:
[Drive Geometry]
	Number of Cylinders:	16383
	Number of Heads:	16
	Sectors Per Track:	63
	Number of Sectors:	16514064
	Total 48-bit LBA Sectors:	976773168
	Logical Sector Size:	512 Bytes
	Cache Buffer Size:	8192 KBytes
[Transfer Modes]
	Sectors Per Interrupt:	Total: 16, Active: 16
	Max. PIO Transfer Mode:	4
	Multiword DMA Mode:	Total: 2, Active: -
	Singleword DMA Mode:	Total: -, Active: -
	Ultra-DMA Mode:	Total: 6 (ATA-133), Active: 0 (?)
	Max. Multiword DMA Transfer Rate:	16.7 MBytes/s
	Max. PIO with IORDY Transfer Rate:	16.7 MBytes/s
	Max. PIO w/o IORDY Transfer Rate:	16.7 MBytes/s
	Native Command Queuing:	Supported, Max. Depth: 32
	TRIM Command:	Not Supported
[Device flags]
	Fixed Drive:	Present
	Removable Drive:	Not Present
	Magnetic Storage:	Present
	LBA Mode:	Supported
	DMA Mode:	Supported
	IORDY:	Supported
	IORDY Disableable:	Supported
[Features]
	Write Cache:	Present, Active
	S.M.A.R.T. Feature:	Present, Active
	Security Feature:	Present, Inactive
	Removable Media Feature:	Not Present, Disabled
	Power Management:	Present, Active
	Advanced Power Management:	Present, Active
	Packet Interface:	Not Present, Disabled
	Look-Ahead Buffer:	Present, Active
	Host Protected Area:	Present, Enabled
	Power-Up In Standby:	Supported, Inactive
	Automatic Acoustic Management:	Not Supported, Inactive
	48-bit LBA:	Supported, Active
	Host-Initiated Link Power Management (HIPM):	Supported
	Device-Initiated Link Power Management (DIPM):	Supported, Disabled
	In-Order Data Delivery:	Not Supported
	Hardware Feature Control:	Not Supported
	Software Settings Preservation:	Supported, Enabled
	NCQ Autosense:	Not Supported
	Link Power State Device Sleep:	Not Supported
	Hybrid Information Feature:	Not Supported
	Rebuild Assist:	Not Supported
	Power Disable:	Not Supported
	Zoned Device ATA Command Set:	Not Supported
	All Write Cache Non-Volatile:	Not Supported
	Extended Number of User Addressable Sectors:	Not Supported
	CFast Specification:	Not Supported
	NCQ Priority Information:	Supported
	Host Automatic Partial to Slumber Transitions:	Supported
	Device Automatic Partial to Slumber Transitions:	Supported
	NCQ Streaming:	Not Supported
	NCQ Queue Management Command:	Not Supported
	DevSleep to Reduced Power State:	Not Supported
	Out Of Band Management Interface:	Not Supported
	Extended Power Conditions Feature:	Not Supported
	Sense Data Reporting Feature:	Not Supported
	Free-Fall Control Feature:	Not Supported
	Write-Read-Verify Feature:	Not Supported
[Security]
	Security Feature:	Supported
	Security Status:	Disabled
	Security Locked:	Disabled
	Security Frozen:	Enabled
	Enhanced Security Erase:	Supported
	Sanitize Feature:	Not Supported
	Sanitize Device - Crypto Scramble:	Not Supported
	Sanitize Device - Overwrite:	Not Supported
	Sanitize Device - Block Erase:	Not Supported
	Sanitize Device - Antifreeze Lock:	Not Supported
	Device Encrypts All User Data:	Not Supported
	Trusted Computing:	Not Supported
[Self-Monitoring, Analysis and Reporting Technology (S.M.A.R.T.)]
	[01] Raw Read Error Rate:	200/51, Worst: 200
	[03] Spin Up Time:	153/21, Worst: 148 (Data = 1333, 0)
	[04] Start/Stop Count:	20/Always OK, Worst: 20 (Data = 80018, 0)
	[05] Reallocated Sector Count:	200/140, Worst: 200
	[07] Seek Error Rate:	200/Always OK, Worst: 200
	[09] Power-on Hours/Cycle Count:	78/Always OK, Worst: 78 (16236 hours / 1.85 years)
	[0A] Spin Retry Count:	100/Always OK, Worst: 100
	[0B] Calibration Retry Count:	100/Always OK, Worst: 100
	[0C] Power Cycle Count:	98/Always OK, Worst: 98 (Data = 2641, 0)
	[BF] G-Sense Error Rate:	1/Always OK, Worst: 1 (Data = 2159, 0)
	[C0] Power-Off Retract Count:	200/Always OK, Worst: 200 (Data = 155, 0)
	[C1] Load/Unload Cycle Count:	152/Always OK, Worst: 152 (Data = 144389, 0)
	[C2] Temperature:	112/Always OK, Worst: 81 (31.0 °C)
	[C4] Reallocation Event Count:	200/Always OK, Worst: 200
	[C5] Current Pending Sector Count:	200/Always OK, Worst: 200
	[C6] Off-Line Uncorrectable Sector Count:	100/Always OK, Worst: 253
	[C7] UltraDMA/SATA CRC Error Rate:	200/Always OK, Worst: 200
	[C8] Write/Multi-Zone Error Rate:	100/Always OK, Worst: 253

AGI250GIMAI238

---

[General Information]
	Drive Controller:	Serial ATA 6Gb/s @ 6Gb/s
	Host Controller:	Intel Tiger Lake PCH-H - SATA Controller (AHCI) [B1]
	Drive Model:	AGI250GIMAI238
	Drive Firmware Revision:	V0718B0
	Drive Serial Number:	AGISASVWK0900323
	Drive Capacity:	238,475 MBytes (250 GB)
	Drive Capacity [MB]:	238475
	Media Rotation Rate:	SSD Drive (Non-rotating)
	Nominal Form Factor:	2.5"
	ATA Major Version Supported:	ATA/ATAPI-5, ATA/ATAPI-6, ATA/ATAPI-7, ATA8-ACS, ACS-2, ACS-3
	ATA Minor Version Supported:	ACS-3 Revision 4
	ATA Transport Version Supported:	SATA 3.2
	Drive Letter(s):	E:
[Drive Geometry]
	Number of Cylinders:	16383
	Number of Heads:	16
	Sectors Per Track:	63
	Number of Sectors:	16514064
	Total 48-bit LBA Sectors:	488397168
	Logical Sector Size:	512 Bytes
	Cache Buffer Size:	N/A
[Transfer Modes]
	Sectors Per Interrupt:	Total: 1, Active: 1
	Max. PIO Transfer Mode:	4
	Multiword DMA Mode:	Total: 2, Active: -
	Singleword DMA Mode:	Total: -, Active: -
	Ultra-DMA Mode:	Total: 6 (ATA-133), Active: 0 (?)
	Max. Multiword DMA Transfer Rate:	16.7 MBytes/s
	Max. PIO with IORDY Transfer Rate:	16.7 MBytes/s
	Max. PIO w/o IORDY Transfer Rate:	16.7 MBytes/s
	Native Command Queuing:	Supported, Max. Depth: 32
	TRIM Command:	Supported (Indeterminate Read After TRIM)
[Device flags]
	Fixed Drive:	Present
	Removable Drive:	Not Present
	Magnetic Storage:	Present
	LBA Mode:	Supported
	DMA Mode:	Supported
	IORDY:	Supported
	IORDY Disableable:	Supported
[Features]
	Write Cache:	Present, Active
	S.M.A.R.T. Feature:	Present, Active
	Security Feature:	Present, Inactive
	Removable Media Feature:	Not Present, Disabled
	Power Management:	Present, Active
	Advanced Power Management:	Present, Inactive
	Packet Interface:	Not Present, Disabled
	Look-Ahead Buffer:	Present, Active
	Host Protected Area:	Present, Enabled
	Power-Up In Standby:	Not Supported, Inactive
	Automatic Acoustic Management:	Not Supported, Inactive
	48-bit LBA:	Supported, Active
	Host-Initiated Link Power Management (HIPM):	Not Supported
	Device-Initiated Link Power Management (DIPM):	Not Supported
	In-Order Data Delivery:	Not Supported
	Hardware Feature Control:	Not Supported
	Software Settings Preservation:	Supported, Enabled
	NCQ Autosense:	Not Supported
	Link Power State Device Sleep:	Not Supported
	Hybrid Information Feature:	Not Supported
	Rebuild Assist:	Not Supported
	Power Disable:	Not Supported
	Zoned Device ATA Command Set:	Not Supported
	All Write Cache Non-Volatile:	Not Supported
	Extended Number of User Addressable Sectors:	Not Supported
	CFast Specification:	Not Supported
	NCQ Priority Information:	Not Supported
	Host Automatic Partial to Slumber Transitions:	Not Supported
	Device Automatic Partial to Slumber Transitions:	Not Supported
	NCQ Streaming:	Not Supported
	NCQ Queue Management Command:	Not Supported
	DevSleep to Reduced Power State:	Not Supported
	Out Of Band Management Interface:	Not Supported
	Extended Power Conditions Feature:	Not Supported
	Sense Data Reporting Feature:	Not Supported
	Free-Fall Control Feature:	Not Supported
	Write-Read-Verify Feature:	Not Supported
[Security]
	Security Feature:	Supported
	Security Status:	Disabled
	Security Locked:	Disabled
	Security Frozen:	Enabled
	Enhanced Security Erase:	Supported
	Sanitize Feature:	Supported
	Sanitize Device - Crypto Scramble:	Not Supported
	Sanitize Device - Overwrite:	Not Supported
	Sanitize Device - Block Erase:	Supported
	Sanitize Device - Antifreeze Lock:	Not Supported
	Device Encrypts All User Data:	Not Supported
	Trusted Computing:	Not Supported
[Self-Monitoring, Analysis and Reporting Technology (S.M.A.R.T.)]
	[01] Raw Read Error Rate:	100/50, Worst: 100
	[05] Reallocated Sector Count:	100/50, Worst: 100
	[09] Power-on Hours/Cycle Count:	100/50, Worst: 100 (7990 hours / 332.9 days)
	[0C] Power Cycle Count:	100/50, Worst: 100 (Data = 875, 0)
	[A0] Uncorrectable Sector Count When Read/Write:	100/50, Worst: 100
	[A1] Number of Valid Spare Blocks:	100/50, Worst: 100 (Data = 100, 0)
	[A3] Number of Initial Invalid Blocks:	100/50, Worst: 100 (Data = 8, 0)
	[A4] Total Erase Count:	100/50, Worst: 100 (Data = 19235, 0)
	[A5] Maximum Erase Count:	100/50, Worst: 100 (Data = 118, 0)
	[A6] Minimum Erase Count:	100/50, Worst: 100 (Data = 26, 0)
	[A7] Average Erase Count:	100/50, Worst: 100 (Data = 87, 0)
	[A8] Maximum Erase Count of Spec:	100/50, Worst: 100 (Data = 5050, 0)
	[A9] Remaining Life:	100/50, Worst: 100 (Data = 99, 0)
	[AF] Program Fail Count In Worst Die:	100/50, Worst: 100
	[B0] Erase Fail Count In Worst Die:	100/50, Worst: 100
	[B1] Total Wear Level Count:	100/50, Worst: 100
	[B2] Runtime Invalid Block Count:	100/50, Worst: 100
	[B5] Program Fail Count (Total):	100/50, Worst: 100
	[B6] Erase Fail Count (Total):	100/50, Worst: 100
	[C0] Power-Off Retract Count:	100/50, Worst: 100 (Data = 8, 0)
	[C2] Temperature:	100/50, Worst: 100 (40.0 °C)
	[C3] Hardware ECC Recovered:	100/50, Worst: 100
	[C4] Reallocation Event Count:	100/50, Worst: 100
	[C5] Current Pending Sector Count:	100/50, Worst: 100
	[C6] Off-Line Uncorrectable Sector Count:	100/50, Worst: 100
	[C7] SATA CRC Error Count:	100/50, Worst: 100
	[E8] Available Reserved Space:	100/50, Worst: 100 (Data = 100, 0)
	[F1] Total Host Writes:	100/50, Worst: 100 (Data = 148415, 0)
	[F2] Total Host Reads:	100/50, Worst: 100 (Data = 492146, 0)
	[F5] Flash Write Sector Count:	100/50, Worst: 100 (Data = 184493, 0)
	Drive Remaining Life	99%
[Device Statistics]
	Lifetime Power-On Resets:	875
	Power-on Hours:	7990
	Logical Sectors Written:	1136637834
	Logical Sectors Read:	2188547550
	Number of Write Commands:	64583581
	Number of Read Commands:	203237601
	Used Endurance Indicator:	2%

NVMe Drives

---

GIGABYTE GP-GSM2NE3256GNTD

---

[General Information]
	Drive Controller:	NVMe (PCIe x4 8.0 GT/s @ x4 8.0 GT/s)
	Host Controller:	Phison Electronics PS5013 PCIe 3.0 x4 NVMe 1.3 SSD Controller
	Drive Model:	GIGABYTE GP-GSM2NE3256GNTD
	Drive Serial Number:	SN214208906049
	Drive Firmware Revision:	EDFM00.7
	NVMe Version Supported:	v1.3
	Drive Capacity:	244,198 MBytes (256 GB)
	Drive Capacity [MB]:	244198
	SCSI Address:	1:0:0:0
	Drive Letter(s):	C:
[Capabilities]
	Volatile Write Cache:	Present
	Compare Command:	Not Supported
	Write Uncorrectable Command:	Supported
	Dataset Management:	Supported
	Write Zeroes:	Supported
	Save field set to a non-zero value:	Supported
	Reservations:	Not Supported
	Timestamp:	Supported
	Autonomous Power State Transitions:	Supported
	Host Memory Buffer (HMB) Capability:	Supported
	Host Memory Buffer (HMB) Minimum Size:	1640 KBytes
	Host Memory Buffer (HMB) Preferred Size:	279344 KBytes
	Host Memory Buffer (HMB) Status:	Enabled
	Host Memory Buffer (HMB) Enabled Size:	64 MBytes
[I/O Command Sets]
	NVM Command Set:	Not Supported
	Key Value (KV) Command Set:	Not Supported
	Zoned Namespace (ZNS) Command Set:	Not Supported
	Subsystem Local Memory Command Set:	Not Supported
	Computational Programs Namespace Command Set:	Not Supported
[Self-Monitoring, Analysis and Reporting Technology (S.M.A.R.T.)]
	Available Space Below Threshold:	OK
	Temperature Exceeded Critical Threshold:	OK
	Device Reliablity Degraded:	OK
	Media In Read Only Mode:	OK
	Volatile Memory Backup Device Failed:	OK
	Drive Temperature:	34 °C
	Warning Temperature Threshold:	85 °C
	Critical Temperature Threshold:	95 °C
	Time Above Warning Temperature Threshold:	0 minutes
	Time Above Critical Temperature Threshold:	0 minutes
	Spare Capacity Available:	100%
	Device Health:	93%
	Power Cycles:	1107
	Power On Hours:	11539 hours
	Unsafe Shutdowns:	9
	Media Errors:	0
	Total Host Reads:	16.95 TBytes
	Total Host Writes:	18.36 TBytes

Network

---

RealTek Semiconductor RTL8168/8111 PCI-E Gigabit Ethernet NIC

---

[General Information]
	Network Card:	RealTek Semiconductor RTL8168/8111 PCI-E Gigabit Ethernet NIC
	Vendor Description:	Realtek Gaming GbE Family Controller
	MAC Address:	D8-5E-D3-41-5A-C2
[Capabilities]
	Maximum Link Speed:	1 Gbps
	Current Link Speed:	1 Gbps
	Transmit Buffer Size:	387584 Bytes
	Receive Buffer Size:	775168 Bytes
	Hardware ID:	PCI\VEN_10EC&DEV_8168&SUBSYS_E0001458&REV_16
[Driver Information]
	Driver Manufacturer:	Realtek
	Driver Description:	Realtek Gaming GbE Family Controller
	Driver Provider:	Realtek
	Driver Version:	10.36.701.2019
	Driver Date:	01-Jul-2019
	DeviceInstanceId	PCI\VEN_10EC&DEV_8168&SUBSYS_E0001458&REV_16\01000000684CE00000
	Location Paths	PCIROOT(0)#PCI(1D00)#PCI(0000)

MERCUSYS Wireless USB Adapter

---

[General Information]
	Network Card:	MERCUSYS Wireless USB Adapter
	Vendor Description:	Microsoft
	MAC Address:	C0-25-2F-B1-27-1B
[Capabilities]
	Maximum Link Speed:	54 Mbps
	Current Link Speed:	54 Mbps
	Transmit Buffer Size:	Unknown
	Receive Buffer Size:	Unknown
